RHH/RHW-2/USE-2 cable has a compact stranded AA-8000 series aluminum alloy conductor with cross-linked polyethylene (XLPE) insulation. It is sunlight, abrasion, moisture and heat resistant.

RHH/RHW-2/USE-2 cable is to be used at conductor temperatures up to 90℃, RHH cable for uses in dry locations and RHW-2/USE-2 cable for uses in dry, damp or wet locations. The voltage rating is 600V.

Applications:

RHH/RHW-2/USE-2 cable is suitable for direct burial or underground duct as specified in the NEC.

Standards:

RHH/RHW-2/USE-2 cable meets UL 44 and UL 854. It has passed the following tests: current overload test, FT2 horizontal flame test, 720h sunlight resistance test, aging test on insulation materials, dielectric voltage withstand test, etc.

Specifications:

Conductor Size （AWG or kcmil）	Nominal Cond. Diameter Normal		Insulation Thickness		Nominal Thickness		Approx. Weight			Allowable Ampacities
Conductor Size （AWG or kcmil）	Inch	mm	mils	mm	mils	mm	Kg/Km	LBS/1000FT	60℃		75℃	90℃
8	0.134	3.4	60	1.52	254	6.4	27	18	35		40	45
6	0.169	4.29	60	1.52	289	7.3	31	21	40		50	55
4	0.213	5.41	60	1.52	333	8.5	37	25	55		65	75
2	0.268	6.81	60	1.52	388	9.9	45	30	75		90	100
1	0.299	7.59	80	2.03	459	11.7	69	46	85		100	115
1/0	0.336	8.53	80	2.03	496	12.6	75	50	100		120	135
2/0	0.376	9.55	80	2.03	536	13.6	81	54	115		135	150
3/0	0.423	10.74	80	2.03	583	14.8	89	60	130		155	175
4/0	0.475	12.07	80	2.03	635	16.1	99	67	150		180	205
250	0.520	13.21	95	2.41	710	18.0	128	86	170		205	230
300	0.570	14.48	95	2.41	760	19.3	139	93	195		230	260
350	0.616	15.65	95	2.41	806	20.5	146	98	210		250	280
400	0.659	16.74	95	2.41	849	21.6	155	104	225		270	305
500	0.736	18.69	95	2.41	925	23.5	169	114	260		310	350
600	0.813	20.65	110	2.79	1033	26.2	216	145	285		340	385
700	0.877	22.28	110	2.79	1097	27.9	230	155	315		375	425
750	0.908	23.06	110	2.79	1128	28.6	237	159	320		385	435
900	0.999	25.37	110	2.79	1219	31.0	254	171	355		425	480
1000	1.060	26.92	110	2.79	1280	32.5	266	179	375		445	500
