G80 Alloy Steel Omega Link Manufacturer

G80 Alloy Steel Omega Link

Request a Quote

View All: http://shenli-rigging.com/2-30-g80-alloy-steel-omega-link.html

Ultimate load is 4 times the Working Load Limit.

Features
● Forged super alloy steel- Quenched and Tempered.
● Suitable for EN818-2 G80 chain.
● Individually proof test at 2.5 times Working Load Limit.
● Fatiuge tested at 1.5 times Working Load Limit for 20000 cycles.
● Breakage test.
● 100% magnaflux crack detection.
● All load pins are 100% individually inspected and tested.
● Surface finish: Powder plastified.
● Colour code: Red RAL3020 / Yellow RAL1003.

Parameters (Unit: mm)

Item Code	Weight (kg)	Woring Load Limit (t)	Breaking Load (t)	A±0.5	B±2	D±1	H±1.5	L±2
8-SLR002-06	0.12	1.12	4.48	8	41	20.5	25	52
8-SLR002-7/8	0.22	2.0	8.0	10	52	23.5	35	68.5
8-SLR002-10	0.36	3.15	12.6	12	62	31.5	40.5	81
8-SLR002-13	0.71	5.3	21.2	15	81	41	54	108
8-SLR002-16	1.3	8	32	19	99	49.5	64	126
8-SLR002-20	2.2	12.5	50	23	118	58	75.6	152

SP- SLR002-SPARE PARTS: LOAD PIN AND SPRING PIN (ELASTIC CYLINDRICAL PIN)

Parameters (Unit: mm)

Item Code	Size	Item Code	Size
SP-SLR002-6	6-8	SP-SLR002-20	20-8
SP-SLR002-7/8	7/8-8
SP-SLR002-10	10-8
SP-SLR002-13	13-8
SP-SLR002-16	16-8
