Mushroom Planting Air Conditioner, 30kW-85kW Air Conditioner Manufacturer

Mushroom Planting Air Conditioner, 30kW-85kW Air Conditioner

Request a Quote

View All: http://ruidonghvac.com/2-4-corrosion-resistant-air-conditioner/index.html

This self-developed mushroom planting air conditioner is made to create an ideal environment for the cultivation of edible mushrooms in factories. The air conditioner integrates several functions, including cooling, heating, air treatment and filtering. With these features, this air conditioner can facilitate the growth of edible mushrooms, such as king trumpet mushrooms, white beech mushrooms, hen-of-the-woods, flammulina filiformis, funcia di basilicu, agaricus bisporus, caterpillar fungas and wood ear.

Download

Technical Parameters

Water Source Unit

Model			Z30GR	Z40GR	Z55GR	Z75GR	Z85GR
Cooling	Cooling capacity	kW	32	41	57	75	85
	Input Power	kW	7.9	10.2	15.9	18.2	18.9
	Running current	A	15.0	19.4	30.3	34.6	36
Heating	Heating capacity	kW	31	39	60	71	80
	Input Power	kW	10	13	19.7	22.1	23.3
	Running current	A	18.8	24.4	37	41.6	43.8
Start mode			Directly start
Adjustment ability			0-50-100%
Refrigerant			R407c/R22
Refrigerant charge		kg	2.5*2	3.2*2	6.5*2	7.5*2	7.5*2
Refrigerant control device			TXV
Compressor	Type		Hermetic scroll compressor
	Qty		2	2	2	2	2
	Power supply		380V/3N/50HZ
Groundwater flow		m³/h	3.30	4.22	6.10	7.73	8.76
Fan	Air Flow	m³/h	6000	8000	12000	15000	15000
	Power	kW	1.5	2.2	4	5.5	5.5
	ESP	Pa	200	250	350	400	400
Application area		m2	200	250	350	450	550
Dimension	L	mm	2080	2080	2400	2400	2400
	W	mm	1180	1180	1410	1410	1410
	H	mm	2050	2050	2200	2200	2200
Air outlet	A	mm	500	500	630	630	630
Air outlet	B	mm	500	500	630	630	630
Return air	C	mm	510	510	740	740	740
Return air	D	mm	810	810	1110	1110	1110
Fresh air	E	mm	210	510	740	740	740
Fresh air	F	mm	810	810	1110	1110	1110
weight		kg	620	660	910	950	980
Note :	Cooling: Well water in/out temperature 18/29℃
Note :	Heating: Well water in/out temperature 15℃/--

Air Cooled Unit

Model			Z30FR	Z40FR	Z55FR	Z75FR	Z85FR
Cooling	Cooling capacity	kW	26	34	47	62	70
	Input Power	kW	10.1	13.1	17	20.8	23.4
	Running current	A	19.1	24.8	32.2	39.5	44.5
Heating	Heating capacity	kW	24	29	40	55	62
	Input Power	kW	9.9	12.9	16.8	20.4	23.2
	Running current	A	18.6	24.2	31.5	38.3	4.7
Start mode			Directly start
Adjustment ability			0-50-100%
Refrigerant			R407c/R22
Refrigerant charge		kg	8	10	14	18	22
Refrigerant control device			TXV
Compressor	Type		Hermetic scroll compressor
	Qty		2	2	2	2	2
	Power supply		380V/3N/50HZ
Groundwater flow		m³/h	10	20	20.00	20	20
Fan	Air Flow	m³/h	6000	8000	12000	15000	15000
	Power	kW	1.5	2.2	3	4	4
	ESP	Pa	200	250	300	350	350
Application area		m2	150	220	300	450	550
Dimension	L	mm	2086	2086	2440	2640	2640
	W	mm	1170	1170	1370	1370	1370
	H	mm	2150	2150	2150	2384	2384
Air outlet	A	mm	500	500	630	630	630
Air outlet	B	mm	500	500	630	630	630
Return air	C	mm	735	735	910	1030	1030
Return air	D	mm	1110	1110	1110	1310	1310
Fresh air	E	mm	358	358	460	460	460
Fresh air	F	mm	1110	1110	1110	1110	1110
weight		kg	540	540	790	830	980
Note :	Cooling: Ambient temperature DB 35 ℃，indoor temperature 21℃
Note :	Heating: Ambient temperature DB 7 ℃，WB 6 ℃

Features

Ensure a clean growth environment for mushrooms;
Able to eliminate contaminated spores;
Equipped with evaporator coil with strong cooling capacity that can bring down indoor temperatures quickly;
Equipped with centrifugal fan that can move large air volume and develop high pressure. The air volume is adjustable.
Equipped with high-performance airtight static pressure fan that makes up high-efficiency filter outlet, which consists of primary and secondary air filters.
Equipped with heat exchanger coils that can cool down environment with refrigerants or water. This means the air conditioner can bring down environment temperatures by moving large volume of air and utilizing water from wells, rivers, lakes, and reservoirs.

Applications

Applicable for cold-temperate mushrooms, such as king trumpet mushrooms, hen-of-the-woods, caterpillar fungas

Treat air for different processes of factory mushroom cultivation, such as cultivating, collecting and packaging;
Multiple functions: cooling, heating, filtering, bringing in fresh air, returning air, moving large volume of air and developing high pressure;
Easily connected with existing air ducts to deliver fresh air;
Able to filter out almost all solids and particulates and to precisely control the composition of air, for instance, the ratio between carbon dioxide and fresh air;
Ensure optimal temperature;
Able to utilize water from natural waterbodies, which will boost cooling capacity and save energy;
In northern China, heating system can use energy provided by the regional central heating system, which makes perfect economic sense for local companies.

Applicable for cold-tolerant mushrooms, such as flammulina filiformis and funcia di basilica

Centrifugal fan can move large volume of air and develop high pressure;
Able to draw in air effectively to ensure temperatures, humidity and carbon dioxide density stay at the same level, which will improve the quality and yields of mushrooms;
Minimize risks of contaminated spores and shorten time required for mushroom maturity;
