8L Oxygen Concentrator

Request a Quote

View All: http://longfiantech.com/2-4-oxygen-concentrator/169347/index.html

Technical Parameters

Model	JAY-8
Flow Rate	0.5-8L/min
Oxygen Purity	93% (±3%)
Outlet Pressure	6-10 PSI (0.04-0.07 Mpa)
Net Weight	26kg
Sound Level	≤50dB
Power Consumption	≤550W
Input Frequency	50Hz; 60Hz
Put Voltage	AC230V ± 10%; AC110V ±10%
Alarm	1. Power failure alarm; 2. High and low pressure alarm; 3. Low oxygen concentration alarm: When oxygen purity is > 82%, blue light illuminates; When oxygen purity is < 82%, red light illuminates for indicating low purity;

Features

With medical grade oxygen concentration above 90%, better treatment effect for patients with pulmonary fibrosis.
Innovative cooling technology ensures 24/7/365 operation.
Humidifier bottle with a pressure relief value of 6PSI, safer and more comfortable.
Features four flexible castors with two brakes, easy to move or situate in any direction, safer and more convenient.
Simple operation functions and easy-to-read LCD display.
Can be connected to HFNC, which provides oxygen with stable high concentration, more comfortable.
It's connected with HBOC to rapidly and effectively increase the patients’ SPO2.

Note
In order to ensure the normal operation of oxygen concentrators, the filter cotton should be cleaned timely. The first and second layer of filter cotton should be cleaned or replaced after the oxygen generator has worked for 200 hours and 500 hours, respectively. Every one or two months, the machine housing can be cleaned by soft towel with little detergent, and then wipe it up with dry towel, under the condition of power off.
