BC05C T-Shape Solar Connector
Request a Quote
Technical Parameters
| Pin Number | 2P PE | |
| General | Main Cable Rated Current | 40A (10AWG/6mm² copper cable) |
| Main Cable Rated Voltage | 300V | |
| Branch Cable Rated Current | 12A (16AWG/1.5mm² copper cable) | |
| Branch Cable Rated Voltage | 300V | |
| Contact Resistance | ≤5mΩ | |
| Power Frequency Withstand Voltage | 1500V AC | |
| Over-Voltage Category | Ⅲ | |
| Closure Pollution Degree | 2(mated) | |
| Protection Class | IP68(1m, 1h) | |
| Withdraw Force | 20~50N | |
| Flammability Rating | UL94-V0 | |
| Rated Temperature | -40℃~ 85℃ | |
| Standards | PPP 59015A:2013 | TUV test standard |
| UL6703A | CSA test standard | |
| Connection Data | Applicable Cable Specification | Main Cable: 14/12/10AWG; branch cable: 16/18AWG |
| Applicable Cable Outer Diameter | Main Cable: 10~13mm; Branch Cable: 7~9.5mm | |
| Locking System | Snap | |
| Connection Type | Main Cable Connection | Crimping |
| Branch Cable Connection | Crimping | |
| Material | Housing Material | PPE |
| Terminal Material | Copper zinc alloy | |
| Terminal Surface Treatment | Main Cable: Tin-Plated; branch cable: gold plated | |
| Sealing Material | Silicon Rubber | |
| Dimensions | Length | 230mm |
| Width | 40mm | |
| Height | 134mm |
