6820GH Group Bus (TOP)

Request a Quote

View All: http://zhongtongbuses.com/3-1-1-6820gh-group-bus/index.html

6820GH series group bus is particularly used for intercity bus. With more than 10 years' improvement and modification, it is won trust from the majority of our customers. The group bus is equipped with luggage compartment. Its 3 3/2 2 seat layout contributes to optimal space utilization. In 2012, we sold 2082 sets of 8-9m group bus to Saudi Arabia. Till now the cumulative sales of 6820GH bus in Saudi Arabia reaches 5000 sets.

Bus parameters	total length (mm)		8220	Engine	model	YC4G180-20/YC4G180-30
	total width (mm)		2360		manufacturer	Yuchai
	total height (mm)		3000/3160		position/fuel	rear
	inner height (mm)		1920		type	straight 4-cylinder; straight
	wheelbase (mm)		3800		max power (kw)	132/132
	front/rear suspension (mm)		1960/2460		max torque (N.M)	660/660
	approach angle/departure angle (º)		10/8		displacement (ml)	5202/5202
	height of single step (mm)		10500
	max total mass defined by factory (kg)		46 1
	rated capacity (person)		100
Item		Standard configuration			Optional configuration
Chassis parameters	chassis	LCK6770RG
	gearbox	CA6-75
	clutch	395 single plate, dry, diaphragm spring
	front /rear axle	4.2T/8T
	suspension	9/11 multi-leaf spring
	steering	Feining power steering system from
	brake	double circuit brake system
	fuel tank	200L
	tire	7.5R20 Double Coin
	accumulator/alternator	24V120Ah/28V/150A from Prestolite
	seat	3 2 layout			2 2, 31 1
