Iris Diaphragm

Request a Quote

View All: http://optical-equipment.com/3-11-iris-diaphragm.html

The iris diaphragm can be used in laser processing, optical experiments and automatic measurement and testing and other places that require to adjustlight beam.

Key Features
Smooth, continuous aperture control.
Wide aperture range.
Compatible with our mounts and positioners.

Specification

Model	WN01ID5	WN0ID10	WN01ID15	WN01ID20	WN01ID25	WN01ID30	WN01ID35	WN01ID40	WN01ID45	WN01ID50	WN01ID55
Aperture	5μm	10μm	15μm	20μm	25μm	30μm	35μm	40μm	45μm	50μm	55μm
Model	WN01ID60	WN01ID65	WN01ID70	WN01ID75	WN01ID80	WN01ID85	WN01ID90	WN01ID95	WN01ID100	WN01ID110	WN01ID120
Aperture	60μm	65μm	70μm	75μm	80μm	85μm	90μm	95μm	100μm	110μm	120μm

(Please enter your desired product model)

Specification

Model	Clear apertureΦ (mm)		External diameterΦ (mm)	Thickness (mm)	Blade number	Material		Installation part
	maximum	minimum				Inner ring	Outer ring(shell)
WN03ID10	10	1	20	5	9	Aluminum	Aluminum	Outer ring

Specification

Model	Clear aperture Φ (mm)		External diameter Φ (mm)	Thickness (mm)	Blade number	Material		Installation part
	maximum	minimum				Inner ring	Outer ring(shell)
WN03ID28B	28	2	49	8	12	Steel	Aluminum	Thread
