Wire Take Up Machine
Request a Quote
This wire take up machine serves to recycle the old conducting wire or the overhead ground wire.
Main Specifications
| Item Number | 08151 | 08152 | |
| Model | SJZ10B | SJZ10C | |
| Engine | Type | Honda GX160 gasoline engine | Z170F diesel engine |
| Power (hp) | 5.5 | 4 | |
| Rotational Speed (rpm) | 3600 | 2600 | |
| Max. Take-up Force (kN) | 13.2 | 10.9 | |
| Take-up Speed (m/min) | 9.8~80 | 10.5~85.4 | |
| Reel Capacity (m) | LGJ95 | 600 | 600 |
| LGJ120 | 460 | 460 | |
| LGJ185 | 320 | 320 | |
| Weight (kg) | 136 | 165 | |
| Overall Dimension (m) | 1.2×0.85×0.95 | 1.2×0.85×0.95 | |
