Movable Turner
Description
The movable turner integrates the crushing function of the later stage of material fermentation. During dehydration, the dehydrated materials can be crushed at the same time. Accordingly, the crushing efficiency of materials are remarkably enhanced to reduce the production cost of an enterprise, which fundamentally solves the problem that the production capacity of traditional turners is restricted by the crusher. The movable turner is especially suitable for producing microorganism fermented materials into excellent bio-organic fertilizer.
Application
The movable turner can effectively mix viscous fermented materials and microbial agents, straw powder evenly, creating a better aerobic environment for material fermentation. Under this loose material character, it takes 24-48 hours for the fermented materials to heat up, three days to deodorize and about 15 days to become fertilizer. This turner requires only one person to drive to operate in open areas, workshops, green houses.
| Model | Capacity | Turning height | Turning width | Motor |
| m3/day | m | m | ||
| ZFP-2000 | 400--500 | 0.5--0.8 | 2 | 32hp, water cooling, point start |
| ZFP-2300 | 500--700 | 0.6--1.0 | 2.3 | 58 hp, water cooling, point start |
| ZFP-2600 | 800--1000 | 0.9--1.3 | 2.6 | 84 hp, water cooling, point start |
| ZFP-3200 | 900-1500 | 1.1--1.6 | 3.2 | 150 hp, water cooling, point start |
| ZFP-3600 | 1000-1800 | 1.2--1.8 | 3.6 | 200 hp, water cooling, point start |
| ZFP-5000 | 2000-3000 | 1.5--2.0 | 5 | 300 hp, water cooling, point start |
