Carbonated Beverage Canning Machine Manufacturer

Carbonated Beverage Canning Machine

Request a Quote

View All: http://beveragefillingline.com/4-1-carbonated-beverage-canning-machine.html

Automatic Can Filler Seamer for Carbonated Soft Drinks

This automatic can filler seamer is designed typically for filling of carbonated beverages in PET or aluminum cans. The carbonated beverage canning machine comprises can filler and can seamer.

Specifications

Model	Production output (330ml can)	Overall dimensions (L×W×H)	Power	Weight
DGD06-1	15-30 c/m	2520×1510×2070mm	3.5 kW	2600 kg
DGD12-1	25-45 c/m	2660×1660×2070mm	3.5 kW	3200 kg
DGD12-4	30-100 c/m	2700×1700×2100mm	5.5 kW	4300 kg
DGD20-4	30-160 c/m	3000×1900×2100mm	5.5 kW	6500 kg
DGD24-4	30-200 c/m	3350×2150×2100mm	5.5 kW	7100 kg
DGD36-6	30-300 c/m	3750×2500×2100mm	7.5 kW	8000 kg
DGD48-6	30-400 c/m	4000×2800×2100mm	11 kW	9500 kg

Details

1. Filling Station
2. The can filler for carbonated beverage adopts counter pressure or Isobaric filling method. Empty cans are moved under filling heads centrally and then lifted and sealed, the filling valve opens simultaneously to allow liquid to flow into cans. Once the set liquid level is reached, the filling process stops automatically.
1. Seaming Station
2. Filled cans are conveyed to the seamer where can lids are placed and attached to the can bodies, and the cans are tightly seamed.

Configurations

Frequency converter: Siemens

PLC: Siemens

Circuit breaker: Siemens

Circuit contactor: Siemens

Thermal relay: Siemens

Proximity switch: Omron

Fiber switch: Omron

Touch screen:: Kinco/Siemens

Pneumatic components: AIRTAC/FESTO

Stainless Steel: POSCO
