Light Tower, H1000 Series
"H1000" series is one of the most powerful Lighting Tower, The hydraulic system with electrical controlling makes every operation to be fast and flexible, more safe and reliable. The six most shining floodlights or twelve LED can illuminate an area of 500 meters radius.
The galvanized mast and the powder coated canopy suit the outdoor environment for a long time. The heavy-duty muffler and the soundproof canopy make the noise level under 70 db(A) 7 meters away.
The electrical controlling hydraulic system with the over center valves and hydraulic lock make every operation smoothly and can keep the hydraulic ram in any position for a long time even when the oil leaks out from the pipes or connecters.
The light bar can be adjusted from horizontal to vertical, and the mast can rotate within 340°by the control panel operation.
The simple and clear graphic indication and operating mark on the control panel. Automatic light control system, all of the light turn off in order.
All the outdoor electrical plugs and sockets and wires are with at least IP44 protective class. The lights are with IP65 or IP66 protective class.
The external IP65 output sockets will power other equipments or electric tools whenever.
The excellent-quality and multi-fault protection generator with the low-emission diesel engine and continuously .The fully bundled tank avoid the fuel spilling out.
The hydraulic legs of individual operation are able to support stably and reliably even on rough ground, so the lighting tower can also work in the 10 grade windy weather.
Option Equipment
Radio remote control system: It can remotely adjust light bar tilt and mast rotation within diameter 100 meters. Another option is SMS remote control function, the lighting tower will be started or stopped remotely by the relative mobile phone, and it can receive the fault alarm message from the lighting tower's controller.
| Standard Equipment | H1000 | |||||
| Length(mm) | 4820(3760,the tow bar be retracted) | |||||
| Width(mm) | 2850(1830,Retracted the legs) | |||||
| Height(mm) | 2920(2380,a pair of top light be detached) | |||||
| Height(Mast be extended fully) | 10050MM | |||||
| Weight (Dry,kg) | 2510 | |||||
| Engine model | YND485 | 404D-22G(Perkins) | ||||
| Frequency(Hz) | 50 | 60 | 50 | 60 | ||
| Speed(rpm) | 1500 | 1800 | 1500 | 1800 | ||
| Continued Power(KVA) | 17 | 20 | 18 | 22 | ||
| Number of Cylinders | 4 | 4 | ||||
| Diesel Engine Characters | 4-cycle,In line, Water cooled Diesel | |||||
| Combustion Type | Indirect injection | |||||
| Engine Aspiration | Natural aspirated | |||||
| Alternator | Brushless & Single phase | |||||
| Rating Voltage(V) | 230/240V | |||||
| Alternator Insulation | Class H | |||||
| Fuel Tank | Bundled Tank | |||||
| Fuel Tank Capacity(L) | 200 | |||||
| Operating hours with full fuel | 50 hours | 52 hours | ||||
| Type of Lights | Metal halide floodlight (Double ends,GEWISS or local brand) | Metal halide floodlight (Double ends,GEWISS) | ||||
| Number & Power of Lights | 6*1500W | 6*2000W | ||||
| Mast Lifting & Extension | Hydraulic operation | |||||
| Mast Rotation | 340°Hydraulic operation | |||||
| Light Bar Tilt | 90° Electric operation | |||||
| Automatic Light Controller | SUNIGHT Controller | |||||
| Stabilizing legs | Hydraulic operation | |||||
| Trailer suspension & braking system | Leaf spring & double axles with electric brakes | |||||
| Hitch & tow bar | Ball or O ring & stable hitch in stable height | |||||
| Tire & rim size | 15" | |||||
| Acoustic pressure | 70dB(A) at 7 meters away | |||||
| Output sockets | 2 Pieces (230/240V,15A) | |||||
| Mining configuration | Be fitted | |||||
| Max.quantity in a 40' container (sets) 40HQ | 3 | |||||
| Optional equipment & upgrades | ||||||
| Cold weather starting kit | | |||||
| Stabilizing legs | Manually | |||||
