Water Resistance Testing Machine (Maeser Water Penetration Tester)
Request a Quote
The Maeser water penetration tester is one type of our water resistance testing machines for leather materials. It is used to evaluate the water resistance of shoe leather as described in ASTM D2099, while the weight and resistance of clean steel balls, which will be placed into test specimens during test, shall conform to this standard too.
This leather testing equipment adopts special design and state-of-the-art sensors, and it will automatically stop registering and display time duration (or cycle number) as soon as water penetrates to the interior or preset test time (or cycle number) expires.
Specification
| Model | ||||
| Position | 4 | |||
| Control method | Touch-screen control, 0~999,999 | |||
| Clamps | V-shaped | |||
| Clamps tip radius | 4mm | 7.5±0.5mm | ||
| Moving fixture flexing displacement | 25.4±1.3 mm | Non required | ||
| Moving fixture flexing angle | Non required | 30 ± 1 ° | 32 ± 1 ° | |
| Test speed | 90±5 r/min | |||
| Shutdown method | Electrode induction | |||
| Sample size | 101.6 x 101.6 mm | 114 x 114 mm | ||
| Power supply | Customizable | |||
| Dimensions( L x W x H ) | 49x45 x45cm | |||
| Weight | 55 kg | |||
| Standards | ASTM D2099 | SATRA TM34 Type 1 | SATRA TM34 Type 2, ISO 5403-2 | |
Standard Accessories
| Stainless steel ball | 550g |
| Electrode induction line | 4pcs |
| Power line | 1pcs |
Option Accessories
| GT-KD20 Hydraulic Rocker Pressure Tester | (Cutter: 101.6x101.6 mm and114 x114 mm) |
| Electronic balance | (300g / 0.01g) |
