M/E Hydraulic Lateral Support Device
Request a Quote
Introduction
The M/E hydraulic lateral supporting device can change the intrinsic frequency of the engine when resonance occurs during normal operation. The M/E hydraulic lateral supporting device protects the engine, and slows degradation of the hull caused by loading and unloading.
Application
M/E hydraulic lateral supporting devices are used in WARTSILA main engines. Specific models can be selected according to the parameters recommended by the main engine factory.
Features
- The M/E hydraulic lateral supporting device consists of the fixed rod of main engine, the adjustable bearer, hydraulic cylinder, hydraulic accumulator and pressure gauge.
- The structure of the hydraulic cylinder comes in two forms for users to choose from: Form I is whole, while Form II is separated into the hydraulic cylinder and hydraulic accumulator. The two sections are connected by 10 x 1 copper pipes, or seamless steel pipes, which are supplied and connected by the shipyard.
Parameters
| Model | Diameter of the piston | Diameter of the piston rod | Piston stroke | Working pressure of oil cylinder | Min. pressure (stroke +16mm) | Max. pressure (stroke-16mm) | Advanced pretension force | Dynamic spring force | Content of accumulator | Pressure of compressed nitrogen to accumulator | Oil type | |
| YHZ 200 | 200mm | 160mm | ±16mm | 5.0MPa | 3.7 MPa | 8.0 Mpa | 100kN | 160kN | 2.5L | 2.0MPa | N32 machine oil | |
| YHZ 160 | 200mm | 160mm | ±16mm | 8.0MPa | 6.0 MPa | 11.5 MPa | 160kN | 270kN | 2.5L | 4.0MPa | N32 machine oil |
