Applications
Cable ties can meet a broad range of requirements from the simple bundling of cables to very specific uses of cable ties under extreme conditions.
Product Materials
Nylon 66, 94V-2 certificated by UL. It features heat-resisting, acid &erosion control, insulate well and not apt to age.
Working Environment
Temperature: -35℃ to 85℃.
Optional Colors
Standard colors (natural or white), UV black and other customized colors are available.
Specifications
| Part No. | Length | Width | Thickness | Head Height | Head Width | MAX Bundle | Min strength | |
| mm | (inch) | mm | mm | mm | mm | mm | kg | |
| CH-3×60 | 60 | 2.4 | 2.2 | 1.0 | 3.4 | 4.35 | 11 | 8(18) |
| CH -3×80 | 80 | 3.2 | 2.2 | 1.0 | 3.4 | 4.35 | 15 | |
| CH -3×100 | 100 | 4 | 2.5 | 1.0 | 3.45 | 4.35 | 22 | |
| CH -3×120 | 120 | 4.7 | 2.5 | 1.1 | 3.55 | 4.6 | 30 | |
| CH -3×150 | 150 | 6 | 2.5 | 1.1 | 3.5 | 4.55 | 35 | |
| CH -3×160 | 160 | 6.3 | 2.5 | 1.1 | 3.5 | 4.5 | 40 | |
| CH -3×200 | 200 | 8 | 2.5 | 1.1 | 3.5 | 4.5 | 53 | |
| CH -4×120 | 120 | 4.7 | 3.6 | 1.2 | 4.3 | 6.05 | 30 | 18(40) |
| CH -4×140 | 140 | 5.5 | 3.6 | 1.3 | 4.3 | 6.05 | 33 | |
| CH -4×150 | 150 | 6 | 3.6 | 1.3 | 4.3 | 6.05 | 35 | |
| CH -4×180 | 180 | 7.1 | 3.6 | 1.3 | 4.45 | 6.2 | 44 | |
| CH -4×200 | 200 | 8 | 3.6 | 1.3 | 4.35 | 6.1 | 53 | |
| CH -4×250 | 250 | 10 | 3.6 | 1.35 | 4.5 | 6.15 | 65 | |
| CH -4×300 | 300 | 12 | 3.6 | 1.35 | 4.4 | 6.15 | 76 | |
| CH -4×370 | 370 | 14.5 | 3.6 | 1.35 | 4.5 | 6.15 | 102 | |
