FCH203 Magnetic Stirrer
Compact magnetic stir plate for mixing and stirring small volume of low viscosity fluid materials
Our compact magnetic stir plate is designed for mixing and stirring small volumes of low-viscosity fluids. This next-generation mini magnetic stirrer features an ultra-thin design and forward-reverse stirring function, making benchtop laboratory mixing more efficient. It significantly reduces rotational instability during speed changes, ensuring optimal stirring performance every time.
- Heating plate size (mm) Ø100
- Max. stirring capacity (H₂O) (ml) 1000
- Input/output power (W) 6/3
- Speed range (rpm) 15-1500
| Model | FCH203 |
| Heating plate size (mm) | Ø100 |
| Max. stirring capacity (H₂O) (ml) | 1000 |
| Input/output power (W) | 6/3 |
| Speed range (rpm) | 15-1500 |
| Min. speed adjustment (rpm) | 10 |
| Allowable ambient temperature (℃) | 5 to 40 |
| Allowable relative humidity (%) | 80 |
| Magnetic stirrer bar dimensions (mm) | Ø7×25 |
| Controller | Touch switch |
| Display | OLED |
| Forward and reverse rotation | Yes |
| Plate material | Tempered glass |
| Body material | Plastic |
| Dimensions (W×D×H) (mm) | 117×180×12 |
| Weight (kg) | 0.30 |
| Protection grade | IP65 |
| Power supply | 1phase AC100-240V,50/60Hz |
The stirrer operates on the principle of magnetic fields, where like poles repel and opposite poles attract. The magnetic field drives a magnetized stir bar placed inside the container to rotate in a circular motion.
This magnetic stirrer is ideal for routine stirring tasks in general research, life sciences, industrial applications, quality analysis, and clinical laboratory settings.
- Adjustable speed control
- Corrosion resistance
- Space-saving compact design
- Low noise level operation with minimal vibration
