Hydraulic Butt Fusion Machine, WP800A
450mm-800mm Plastic Pipe Welding Machine
The butt fusion jointing machine implements HDPE, PP, PVDF, MPP pipes and fittings connections through butt fusion welding process.
- Model: WP800A
- Welding range: 450-800 mm
- Applicable pipe diameters: 630-710-800 mm
- Optional reducers: 450-500-560mm
- Power supply: 380 V/50Hz, 3PH
- Total power: 16.2 kW
- Heating plate: 12.5 kW
- Planing tool: 2.2 kW
- Hydraulic station: 1.5 kW
- Pressure adjusting range: 0-16 MPa
- Max temperature of heating plate: 270 ºC
- Temperature deviation: ±7 ºC
WELPING hydraulic butt fusion welding machine is designed to weld HDPE, PP, PVDF, MPP pipes.
-
-
-
The butt fusion equipment features a sturdy and distortion-free machine frame which is ideally suitable for heavy-duty operations.
-
-
-
The machine frame features high strength, outstanding precision, and lighter components weight for lower work load and better welding performance.
-
-
-
The hydraulic station is designed with an enclosed structure to prevent dirt or water. The hydraulic butt fusion machine employs an intuitive LCD display panel integrating various operations to improve operational efficiency.
-
-
-
Copper coil motor has a self-locking system to prevent damages caused by misoperation. High-speed steel reducer inserts with double cutting edges are highly durable.
-
-
-
High quality resistance wire delivers efficient and even heating performance. The heating element is applied with superior Dupont or Daikin coating.
