NNC69K-2Z Mini Electromagnetic Relay

NNC69K-2Z Mini Electromagnetic Relay
NNC69K-2Z Mini Electromagnetic Relay
NNC69K-2Z Mini Electromagnetic Relay
Request a Quote

The NNC69K-2Z mini electromagnetic relay can be applied to household appliances, PCB circuit board, industrial control system and automatic control system, etc.

Features
  • The NNC69K-2Z mini electromagnetic relay provides changeover contacts that include one group of (NO:15A/NC:12A) and two groups of (8A).
  • The device can directly welded on the printed circuit board and has the socket type installation mode.
Identification

CCC: 2011010303471250

Model explanation
Contact parameters
Contact form 2Z,2H,2D
Contact load 8A 1/3HP
Maximum switching voltage 277VAC 8A
30VDC 8A
Contact material Silver alloy
Relay coil
Rated voltage V DC12V DC24V DC48V DC110V
Rated current (±10%) mA 44 22 11 4.8
Coil resistance (±10%) Ω 272 1090 4363 22916
Rated power consumption W 0.53W
Pull-in voltage (Maximum) V Below %
Drop-out voltage(Minimum) V Above10%
Allowable voltage(Maximum) V Rated voltage×110%
Rated voltage V AC12V AC24V AC110V AC220V
Rated current (±10%) mA 83.3 41.6 9 4.5
Coil resistance (±10%) Ω 50 202 4278 17111
Rated power consumption W 1.0VA
Pull-in voltage (Maximum) V Below 80%
Drop-out voltage(Minimum) V Above 30%
Allowable voltage(Maximum) V Rated voltage×110%
Specification of NNC69K-2Z mini electromagnetic relay
Coil voltage DC:3 - 110V AC:6-240V
Pull-in time ≤20ms
Drop-out time ≤10ms
Withstand voltage Between the homopolar contacts 1200VAC/1min(Leakage current 1mA)
Between the heteropolar contacts 1200VAC/1min(Leakage current 1mA)
Between contacts and coil 5000VAC/1min(Leakage current 1mA)
Dimension 28.8 × 12.7 ×27mm
Weight About 20g
Dimension and installation

① Front view; ② Side view; ③ Installation size; ④ Wiring diagram
