WN265TA(15-50)H Compact Motorized Stage
Request a Quote
WN265TA30H compact motorized stage is suitable for providing linear displacement by electric control in automatic displacement control in scientific research, full-automatic measuring and testing equipment, industrial automation and other fields. It is small, light and is suitable for low speed and low load situation.
Parameter table of WN265TA(15-50)H Compact Motorized StageModel | WN265TA15H | WN265TA30H | WN265TA50H |
Travel | 15 mm | 30 mm | 50 mm |
Table Size | 40×25mm | 40×25mm | 40×25mm |
Screw type | Ground lead screw (lead 0.5mm) | Ground lead screw (lead 1mm) | |
Stepper Motor (1.8°) | 20STH30-0604A | ||
Load Capacity | 5kg | ||
Weight | 2.2kg | 2.75kg | 3kg |
Resolution | 2.5μ (Non-MS driver) 0.125μ (20 MS driver) | 5μ (Non-MS driver) 0.25μ (20 MS driver) | |
Maximum Speed | 5mm /sec | 10mm /sec | |
Repeatability | 2μ | 2.5μ | |
Positional Accuracy | 8μ | ||
Straightness | 5µ | 8µ | |
Driving Parallelism | 10µ | 15µ | |
Pitching | 25″ | ||
Yawing | 20″ | ||
Backlash | 1µ | ||
Runout | 1µ | ||
- Equipped with standard stepper motor and RS232 interface, the WNSC series motion controller which was independently developed by BJWN can realize automatic motion control.
- High quality precision ground lead screw drive, small lead, same micro-steps can realize high resolution.
- The clearance of the ground lead screw can be minimized by the structure design of eliminating backlash nuts.
- Cross roller guide, stable, adjustable for the pre-tension force of guide and eliminating clearance, could be used in multi-dimensional combination.
- Greatly reduce the pitching and yawing of the motorized stage through the ground base plate and the reasonable mounted guide, so as to effectively improve the straightness and driving parallelism.
- Connected the stepper motor and ground lead screw by high quality flexible coupling, drive synchronization, good for eliminating eccentricity and greatly reducing eccentricity disturbance, lower noise.
- Install zero and limit switches at both ends for accurate positioning and product protection.
- The base has tapped hole and through hole with standard spacing for the convenience of installation and fixation.
- Accept customized installation of servo motor and linear scale.
