WN220TA(50-300)H Motorized Linear Stage
Request a Quote
WN220TA(50-300)H motorized linear stage, equipped with high precision ball screw, is ideally suitable for industrial automation, laboratory working or other heavy workload. Motorized by high precision ball screw, the linear stage has good repeatability and positional accuracy. The linear stage is also equipped with dustproof cover. You can choose to add grating scale to form closed loops, or change the motor to servo motor. This type of linear stage provides linear displacement by electric control in automatic displacement control in scientific research and full-automatic measuring. You can choose from 5 models with a wide travel range from 50mm~300mm.
Model | WN220TA50H | WN220TA100H | WN220TA150H | WN220TA200H | WN220TA300H | ||
Structure | Travel | 50 mm | 100 mm | 150 mm | 200 mm | 300 mm | |
Table Size | 115×115mm | 115×115mm | 115×115mm | 115×115mm | 115×115mm | ||
Screw Type | High precision ball screw (lead 4mm) | ||||||
Guide Rail | High precision linear guide | ||||||
Stepper Motor (1.8°) | STP-42D3016 | ||||||
Material | Aluminum alloy | ||||||
Surface | Blackened by anodic oxidation | ||||||
Load Capacity | 15kg | 10kg | 7 kg | 5kg | |||
Weight | 2.8kg | 3.4kg | 4.5kg | 5.2kg | 6.3kg | ||
Accuracy | Resolution | 20μ(Non-MS driver) 1μ(20 MS driver) | |||||
Maximum Speed | 25mm/sec | ||||||
Repeatability | 1μ | ||||||
Positional Accuracy | 3μ | ||||||
Straightness | 2µ | 4µ | 6µ | ||||
Driving Parallelism | 10µ | 12µ | 15µ | ||||
Pitching | 25″ | 50″ | 60″ | ||||
Yawing | 20″ | 25″ | 30″ | ||||
Backlash | 2µ | ||||||
Runout | 2µ | 3µ | |||||
Accessories | Able to add failsafe system (Z) | ||||||
Able to add grating scale (G) | |||||||
Able to servo motor(D) | |||||||
able to add dustproof cover (F) | |||||||
