Pre-Heating Machine

Request a Quote

View All: http://jl-rubbermachine.com/1-1-5-pre-heating-machine.html

Used for heating metal carrier of vulcanized rubber seal

JXR-X-I

JXR-X-Ⅱ

JXR-X-Ⅲ

JXR-X-IV

JXR-X-V

In traditional vulcanization processing, in order to ensure better adhesion between the metal carrier and rubber seal and avoid changes in rubber quality due to prolonged vulcanization time, the carrier can be preheated using heating equipment. Julong can provide various heating equipment such as hot air heating, infrared heating, and flame heating machines according to different processing needs.

Applications
Used for cleaning rust preventive oil on the surface of the carrier, preheating and removing moisture from the carrier, enabling better adhesion with rubber.

Specifications

Model	Heating Method	Applicable Carrier	Effective Heating Length	Note
JXR-X-Ⅰ	Infrared heating	Suitable for all types of carrier materials	1m	Max. temperature: 350℃
JXR-X-Ⅱ	Infrared heating flame heating torch	Suitable for all types of carrier materials	1m	Max. temperature: 350℃
JXR-X-Ⅲ	Blow-in hot air heating	Suitable for all types of carrier materials	1m	Max. temperature: 300℃
JXR-X-Ⅴ	Hot air heating	Suitable for all types of carrier materials	25m	Max. temperature: 200℃
JXR-X-IⅤ	Ultrasonic induction heating	Suitable for steel strips and stainless steel strips.	—	Adjustable power
