Descriptions

The Z series vibrating feeder is used primarily to uniformly and continuously provide materials to the crusher. When materials go through the screen strip on the tank, smaller materials will fall through the gaps without being crushed, thus improving the later crushing efficiency.

This vibrating crusher is a large capacity feeder, and will easily accept a degree of crushing and padding pressure to larger materials. The maximum feeding granularity of this feeder is 1.2m, and the maximum hopper capacity is 250 cubic meters.

Applications

The vibrating feeder provides stable materials for the crusher, while screening out relatively small sand and gravel particles in processing sites for mining, limestone, and ceramics, as well as a variety of crushing industries, including building materials crushing, coal mine crushing, metallurgical crushing and metal ore crushing.

Various Crusher Models
Model Double vibration amplitude (mm) Processing capacity(t/h) Rotate speed (r/min) Incidence (°) Motor power (kw) Weight (t) Size L*W*H
(mm )
HZ1860 8-11 800-1500 830 18° 45 10.2 6000*3440*3326
HZ1660 8-11 700-1400 45 9.7 6000*2300*2770
HZ1560 8-11 600-1200 45 8.3 6000*2300*2770
HZ1260 8-11 500-800 37 7.3 5500*2000*2610
HZ1150 8-11 450-700 30 6.5 5000*2000*2450
HZ1620 6-10 550-1200 930 18° 15 4 2000*2300*1515
HZ1420 8-10 450-1000 15 3.3 2000*2200*1515
HZ1220 6-10 350-800 11 3 2000*1980*1096
HZ1020 6-10 300-600 11 2.6 1800*1780*1043
