Broke Pulper

Request a Quote

View All: http://fjlime.com/1-10-broke-pulper.html

The broke pulper can deal with moist or dry broke continuously or intermittently. It is used extensively in waste paper recycling and paper making fields.

Structure Features

Our broke pulper is mainly composed of ferroconcrete vat, horizontal impeller, and drive mechanism. The paper stock enters the vat through the upper inlet and then is ejected at a high speed, forming fierce turbulence and generating large internal friction force in the vat. Under the action of this intensified force, the paper stock is defiberized.

Specifications of Broke Pulper

Model	Capacity (t/24h)	Rotor Diameter (mm)	Hole Size (mm)	Stock Consistency (%)	Motor Power (KW)
ZDS111 ~ 161	50 ~ 100	Φ 2500	Φ15 ~ 20	3 ~ 4.5	55
ZDS112 ~ 162	100 ~ 300	Φ 2750			110
ZDS113 ~ 163	150 ~ 400	Φ 3000			132
ZDS114 ~ 164	250 ~ 500	Φ 3250			200
ZDS115 ~ 165	350 ~ 600	Φ 3500			250
ZDS116 ~ 166	450 ~ 800	Φ 3750			315
ZDS111/2 ~ 161/2	100 ~ 200	Φ 2500			55×2
ZDS112/2 ~ 162/2	200 ~ 600	Φ 2750			110×2
ZDS113/2 ~ 163/2	300 ~ 800	Φ 3000			132×2
ZDS114/2 ~ 164/2	500 ~ 1000	Φ 3250			200×2
ZDS115/2 ~ 165/5	750 ~ 1200	Φ 3500			250×2
ZDS116/2 ~ 166/2	900 ~ 1600	Φ 3750			315×2

Note: Please don't cast flexible objects such as ropes, plastics and rubbers, which are hard to crush, into the vat.
