Corrugated Slitting and Cutting System, Servo Control
Request a Quote
View All: http://corrugating-machine.com/1-11-4-corrugated-slitting-and-cutting-system-servo-control.html
This product has been discontinued and removed from our shelves.
Corrugated Board Manufacturing
Specifications
-
- Design speed
- 100 cuts/min
-
- Machine speed
- 80-100 cuts/min
-
- Max. working width
- 1800mm(70.87")
-
- Cutting length
- 400mm-2999mm(15.75-118.07")
-
- Cutting precision
- ±3-5mm(0.12-0.20") (constant speed)
-
- Relative humidity
- 20%-90%
-
- Relative temperature
- 5℃-50℃
-
- Voltage
- 380V
-
- Frequency
- 50Hz
-
- Motor power
- 14.5kW
Features
- Slitting unit adopts Delta Electronics (Taiwan) A2 servo control system, providing stable performance and precise cut size;
- Each blade is equipped with an independent servo drive, greatly shortening order change cycle (2-3 seconds only) while reducing the waste of material and lowering manufacturing cost;
- Delta Electronics PLC, CANopen Bus control system, real-time data transmitting, lower failure rate;
- HMI interface with 10" color touch screen;
- Up to 999 orders can be stored, can meet customer's specific production demands;
- Cut-off unit is servo controlled;
- Stacking speed is controlled with variable frequency drive;
