2024 Aluminum Alloy
Request a Quote
Application
2024 aluminum is suitable for project requiring a high strength-to-weight ratio and excellent fatigue resistance, often used in the aerospace industry, like wing and fuselage structures, rivets, skin, skeleton parts, etc.
Aluminum alloy state, size and mechanical properties| Alloy | Temper | Thickness (mm) | Tensile strength (Mpa) | Elongation (%) | |
| Chinese standard | Value | ||||
| 2024 | O | ＞0.4-1.5 | ≥220 | ≥220 | ≥12 |
| ＞1.5-3.0 | ≥13 | ||||
| ＞3.0-6.0 | |||||
| ＞6.0-9.0 | |||||
| ＞9.0-12.5 | |||||
| ＞12.50-25.0 | - | ||||
| T3 | ＞0.4-1.5 | 435 | 435 | ≥12 | |
| ＞1.5-3.0 | 435 | 435 | ≥14 | ||
| ＞3.0-6.0 | 440 | 440 | ≥14 | ||
| ＞6.0-12.5 | 440 | 440 | ≥13 | ||
| ＞12.5-40.0 | 430 | 430 | - | ||
| ＞40.0-80.0 | 420 | 420 | - | ||
| ＞80.0-100.0 | 400 | 400 | - | ||
| ＞100.0-120.0 | 380 | 380 | - | ||
| ＞120.0-150.0 | 360 | 360 | - | ||
| T4 | ＞0.4-1.5 | 425 | 425 | ≥12 | |
| ＞1.5-6.0 | 425 | 425 | ≥14 | ||
| T8 | ＞0.4-1.5 | 460 | 460 | ≥5 | |
| ＞1.5-6.0 | 460 | 460 | ≥6 | ||
| ＞6.0-12.5 | 460 | 460 | ≥5 | ||
| ＞12.5-25.0 | 455 | 455 | - | ||
| ＞25.0-40.0 | 455 | 455 | - | ||
| F | ＞4.5-80.0 | - | - | - | |
