10T Truck Cranes, STSQ10T
Request a Quote
STSQ10T is a 10-ton truck-mounted crane with a telescopic boom that can extend to the maximum length of 33m. A horizontal supporting cable is equipped to ensure that the telescopic boom extents and retracts freely in horizontal position. This mobile crane is configured with 15kW motor, double-section stabilizer legs, Tangjun chassis with small turning radius and 360-degree rotating platform, making the crane truck to work stably and efficiently in limited spaces.
Features
- Outrigger system of hydraulic double-section stabilizer legs, wider outrigger span ensures stable operation;
- 6-section telescopic boom of U-shaped cross section can be extended to its maximum length of 33m, the maximum loading capacity of 10 tons, the maximum working radius of 22m, providing better stability than other mobile cranes with equivalent load capacity;
- This mobile crane can be operated with either fuel oil or electricity, it can be directly connected to 380V standard industrial power for more energy efficient and maintenance-free operation;
- Standard connectors and cables are configured for easy operation;
- Newly developed hydraulic system ensures high working efficiency and low energy consumption;
- 360-degree rotating platform;
- Max. loading capacity
- 10t
- Max. lifting height
- 33m
- Longitudinal outrigger span
- 5.1m
- Transversal outrigger span
- 4.13m
- Boom
- 6 sections (6.5m per section)
- Dimensions
- 9.24m*2.15m*3.2m
- Motor power
- 15kW, 380V, 50Hz, 3 Phase
- Tyres
- 825R16
- Wheelbase
- 3500mm
- Crane weight
- 11200kg
