In Line Check Valves, Vertical or Horizontal Installation
Request a Quote
- Working pressure: 250 PSI
- Temperature range: -40 °F to 450°F (-40℃ to 230℃)
- Cracking pressure: 3 PSI
- Applications: Air compressor discharge hose assemblies, may also be used in the water or oil industry
| Part # | Part Name | Material |
| 6 | Plug | Brass |
| 5 | Body | Bronze |
| 4 | Gasket | PTPF |
| 3 | Spring | S.S |
| 2 | O-ring | HNBR |
| 1 | Cap | Brass |
| Item # | Size | W | L | H | ||
| In. | mm | In. | mm | |||
| 1/8'' | 1/8 | 1.75 | 44.45 | 1.63 | 41.40 | |
| 1/4'' | 1/4 | 1.75 | 44.45 | 1.63 | 41.40 | |
| 3/8'' | 3/8 | 2.19 | 55.63 | 1.88 | 47.75 | |
| 1/2'' | 1/2 | 2.50 | 63.50 | 2.13 | 54.10 | |
| 3/4'' | 3/4 | 2.88 | 73.15 | 2.50 | 63.50 | |
| 1'' | 1 | 3.50 | 88.90 | 2.88 | 73.15 | |
| Part # | Part Name | Material |
| 9 | Plug | Brass |
| 8 | Body | Bronze |
| 7 | Valve Core | Bronze |
| 6 | Gasket | PTPF |
| 5 | Seal Pad | Brass |
| 4 | Nut | Brass |
| 3 | Spring | S.S |
| 2 | O-ring | HNBR |
| 1 | Cap | Brass |
| Item # | Size | W | L | H | ||
| In. | mm | In. | mm | |||
| 1/4'' | 1/4 | 2.19 | 55.63 | 2.38 | 60.45 | |
| 3/8'' | 3/8 | 2.38 | 60.45 | 2.52 | 64.01 | |
