Vertical Low Viscosity Piston Filler

Request a Quote

View All: http://fillinglinecn.com/1-3-2-vertical-low-viscosity-piston-filler.html

Application

The vertical low viscosity piston filler can fill materials with low viscosity and high fluidity, including industrial potting sealant, modified silane adhesive, plastic tube electronic adhesive, etc.

Description

This vertical piston filler adopts vertical filling and vertical plunger inserting mode. One can perform plunger inserting while filling at the same time.

Technical parameters

Filling speed	20-25 cartridges/min
Filling accuracy	±1g/300ml
Filling range	240ml-320ml (customization is offered for larger capacity)
Overall power	7KW
Gas pressure	0.7MPa
Gas consumption	90L/min
Working pressure of hydraulic system	6-8Mpa
Hydraulic cooling mode	Air cooling
Machine size (L x W x H)	1450x1200x1820mm
Net weight	0.8T

Note: Great is able to match the voltage and frequency of the fillers according to clients from different regions.

Features

Vertical filling

01: Metering mechanism
02:Filling sealant outlet
Manual filling, outlet has built-in check valve to avoid spill after filling.
Vertical plunger inserting

01: Cylinder actuator B
02: Capping mould
03: Bottle position C for capping
04: Cylinder actuator A
The plunger inserting mechanism has built-in discharge device and cylinder stroke limit device to avoid spill and bubble during the cap inserting process.
