Cell Culture Bioreactor

Request a Quote

View All: http://pharma-stainless.com/1-4-cell-culture-bioreactor.html

The cell culture bioreactor is a multifunctional bioreactor, which is mainly used on the biopharmaceutical field, like the production of monoclonal antibody, insulin, albumin, vaccine, and blood products

Support processes including batch, fed-batch
Able to mix the hydrogen, carbon monoxide, nitrogen and methane together
With mixing, feed pump and foam breaker and other functions
Available with PLC system to monitor the pH, DO, backpressure, liquid level, temperature and other important parameters.

Details

Raw material
The material of cell culture bioreactor is autoclavable borosilicate glass or 316L stainless steel
Surface treatment
The interior of tank is electropolishing finish withRa≤0.28um while the outer surface is matt finish or brushed finish.
Magnetic fluid seal
Adopt advanced magnetic fluid seal technique and aerator with hollow shaft to prevent the powder caused by mechanical sealing.
Precise filters
The gas going in and out the cell culture tank all goes through the filter to avoid contamination caused by bacteria outside or inside.

Specifications

Total amount	2.5L	5L	7L	14L	30L	40L	75L	150L	300L
Sterilization system	Off-line sterilization				In-line automatic sterilization
Mixing system	Stir up				Stir up/Stir down
Mixing control	0-300rpm,±1rpm
Ventilation mode	Central ventilation				Central ventilation/Side ventilation
Control system	Siemens S1200				Siemens S1500
IPC	40 cm				50 cm
Liquid level control	Conductivity electrode				Conductivity electrode /Weigh system
PH control	2.00-14.00,±0.1pH
DO control	0-200%,±1%
Back pressure control	Manual/Automatic
Monitoring software	NetSCADA
Database	Access/SQL
