Finger Joint Cutters
Request a Quote
Materials
Cutter body is made by high grade steel sheet, and cutter head is inlaid with hard alloy.
Application
Suitable for joining and splicing of all types of softwood and hardwood.
Regular size (outer diameter x thickness x Z)
- 160 x 4.0 x 2T
- 160 x 4.0 x 4T
- 160 x 10.0 x 4T
- 210 x 4.0 x 4T
- 250 x 4.0 x 6T;
Bore is 30, 35, 40, 50, 70 mm. Thickness of the middle and bottom insert knife is 4.0mm and 10.0mm, respectively. Regular finger joint length is 11.5, 12, 14 and 16mm, as well as customized length following customer demands.
Specifications
| Outer diameter | Thickness | Bore | Z |
| 160 | 4.0 | 40/50/70 | 2 |
| 160 | 10.0 | 40/50/70 | 2 |
| 160 | 4.0 | 40/50/70 | 4 |
| 160 | 10.0 | 40/50/70 | 4 |
| 180 | 4.0 | 40/50/70 | 2 |
| 180 | 10.0 | 40/50/70 | 2 |
| 180 | 4.0 | 40/50/70 | 4 |
| 180 | 10.0 | 40/50/70 | 4 |
| 210 | 4.0 | 40/50/70 | 4 |
| 210 | 10.0 | 40/50/70 | 4 |
