SDEC Engine Series

Powered by SDEC diesel engine

Our SDEC engine series diesel generator sets are engineered with a focus on integration and efficiency. These gensets feature an integral crankshaft, gantry frame, flat cutout connecting rods, and short pistons, which contribute to their compact and practical design. By reducing the number of external circuits and parts, these generators enhance system reliability and maintenance ease. The incorporation of an integral brushless alternator significantly improves the system's leak resistance and overall dependability. With strong performance capabilities in high-altitude environments, these generators are ideal for challenging operational conditions. Below are the specifications for our 600-1000KW SDEC engine series diesel generator sets.

600kW/750kVA

Diesel Generator Set with SDEC Engine, DB-600GF

  • Prime power: 600kW/750kVA
  • Standby power: 660kW/825kVA
  • Rated current: 1080A
  • Rated voltage: 400V/230V Customized
  • Frequency: 50Hz
  • Engine: Shangchai SC33W990D2
  • Alternator: Stamford/Leroy Somer/Engga (optional)

650kW/813kVA

Diesel Generator Set with SDEC Engine, DB-650GF

  • Prime power: 650kW/813kVA
  • Standby power: 720kW/900kVA
  • Rated current: 1170A
  • Rated voltage: 400V/230V Customized
  • Frequency: 50Hz
  • Engine: Shangchai 6KTAA25-G31
  • Alternator: Stamford/Leroy Somer/Engga (optional)

720kW/900kVA

Diesel Generator Set with SDEC Engine, DB-720GF

  • Prime power: 720kW/900kVA
  • Standby power: 800kW/1000kVA
  • Rated current: 1296A
  • Rated voltage: 400V/230V Customized
  • Frequency: 50Hz
  • Engine: Shangchai 6WTAA35-G32
  • Alternator: Stamford/Leroy Somer/Engga (optional)

800kW/1000kVA

Diesel Generator Set with SDEC Engine, DB-800GF

  • Prime power: 800kW/1000kVA
  • Standby power: 880kW/1100kVA
  • Rated current: 900A
  • Rated voltage: 400V/230V Customized
  • Frequency: 50Hz
  • Engine: Shangchai 6WTAA35-G31
  • Alternator: Stamford/Leroy Somer/Engga (optional)

1000kW/1250kVA

Diesel Generator Set with SDEC Engine, DB-1000GF

  • Prime power: 1000kW/1250kVA
  • Standby power: 1100kW/1375kVA
  • Rated current: 1800A
  • Rated voltage: 400V/230V Customized
  • Frequency: 50Hz
  • Engine: Shangchai 6WTAA35-G311
  • Alternator: Stamford/Leroy Somer/Engga (optional)
Speed: 1500rpmCylinders No. & Type: 6 cylinders, Inline, 4 stroke, diesel engine, water-cooled
