5086 Aluminum Alloy
Request a Quote
5086 aluminum sheets/plates available size range
- Thickness: 0.2-200mm
- Width: 30-2500mm
- Length: 500-13000mm
- Thickness: 0.2-6.35mm
- Width: 500-2500mm
Application
5086 alloy is used in shipyards, marine components, military and defense applications (such as armor plating, tanks, armored personnel carriers, missile components), unfired and welded pressure vessels, auto aircraft cryogenics, TV towers, drilling rigs, transportation equipment, tanks and marine components.
Aluminum alloy state, size and mechanical propertiesAlloy | Temper | Thickness (mm) | Tensile strength (Mpa) | Elongation (%) | |
Chinese standard | Value | ||||
5086 | O H111 | >0.20-0.50 | 240-310 | 240-310 | ≥11 |
>0.5-1.50 | ≥12 | ||||
>1.5-3.0 | ≥13 | ||||
>3.0-6.0 | ≥15 | ||||
>6.0-12.50 | ≥17 | ||||
>12.5-150.0 | - | ||||
H22 H32 | >0.2-0.50 | 275-335 | 275-335 | ≥5 | |
>0.5-1.50 | ≥6 | ||||
>1.5-3.0 | ≥7 | ||||
>3.0-6.0 | ≥8 | ||||
H24 H34 | >0.2-0.50 | 300-360 | 30-360 | ≥4 | |
>0.5-1.50 | ≥5 | ||||
>1.5-3.0 | ≥6 | ||||
>3.0-6.0 | ≥7 | ||||
H26 H36 | >0.2-0.50 | 325-385 | 325-385 | ≥2 | |
>0.5-1.50 | ≥3 | ||||
>1.5-3.0 | ≥3 | ||||
>3.0-4.0 | ≥3 | ||||
H112 | >6.0-12.5 | ≥250 | ≥250 | ≥8 | |
>12.5-40.0 | ≥240 | ≥240 | - | ||
>40.0-80.0 | ≥240 | ≥240 | - | ||
F | >4.50-150 | - | - | - |
