Shipbuilding Gantry Crane
Request a Quote
Shipbuilding gantry cranes are specially used for the transportation and docking of debris in docks (or berths). They have the characteristics of large lifting capacity, large span, high work efficiency and multiple functions. This crane equipment has a variety of functions such as lifting, pneumatic steering. It has two forms of single-beam and double-beam gantry, as well as rigid legs of one-column and double-post gantry.
Specification
Lifting capacity | 2x25t 100t | 2x75t 100t | 2x100t 160t | 2x150t 200t | 2x400t 400t |
Total lifting capacity | 150t | 200t | 300t | 500 | 1000 |
Span | 50m | 70m | 38.5m | 175 | 185 |
Max. wheel load | 260kN | 320kN | 330kN | 700 | 750 |
Total power | 400kW | 530kW | 650kW | 1550 | 1500 |
Span | 40~180m | ||||
Lifting height | 25~60m | ||||
Working class | A5 | ||||
Power source | 3-phase AC 380V50Hz or as required |
Features
- The cost is lower, which can reduce the cost of plant construction
- High working efficiency
- Wide application scenarios
- Stable performance, simple and convenient daily maintenance
- Safe and reliable
