EDS1000 Series Variable Frequency Drive
Features
1. Space voltage vector PWM control
2. Compact design for versatile installations
3. Automatic voltage regulation ( AVR) and automatic current limiting function
4. Built-in PID controller, can realize constant pressure (flux etc.) “One drive multiple device” control (Optional Function)
5. 16 (Maximum) section speed control and simple spinning traverse function
6. 0-20KHz pulse input-output interface is convenient for making up digital closed-loop control systems
7. RS485 communication interface can be built inside the inverter to realize centralized control and perform auxiliary consecutive action control easily
Input Voltage | Inverter type | Rated Output Current(A) | Adaptable Motor (KW) |
3 phase 220V | EDS1000-2T0007 | 4 | 0.75 |
EDS1000-2T0015 | 7 | 1.5 | |
EDS1000-2T0022 | 10 | 2.2 | |
EDS1000-2T0037 | 15 | 3.7 | |
EDS1000-2T0055 | 24 | 5.5 | |
EDS1000-2T0075 | 32 | 7.5 | |
Single phase 220v | EDS1000-2S0004 | 3 | 0.4 |
EDS1000-2S0007 | 4.7 | 0.75 | |
EDS1000-2S0015 | 7.5 | 1.5 | |
EDS1000-2S0022 | 10 | 2.2 | |
EDS1000-2S0037 | 15 | 3.7 | |
3 phases 380v | EDS1000-4T0007G/0015P | 2.3/3.7 | 0.75/1.5 |
EDS1000-4T0015G/0022P | 3.7/5 | 1.5/2.2 | |
EDS1000-4T0022G/0037P | 5/8.5 | 2.2/3.7 | |
EDS1000-4T0037G/0055P | 8.5/13 | 3.7/5.5 | |
EDS1000-4T0055G/0075P | 13/17 | 5.5/7.5 | |
EDS1000-4T0075G/0110P | 17/25 | 7.5/11 | |
EDS1000-4T0110G/0150P | 25/33 | 11/15 | |
EDS1000-4T0150G/0185P | 33/39 | 15/18.5 | |
EDS1000-4T0185G/0220P | 39/45 | 18.5/22 | |
EDS1000-4T0220G/0300P | 45/60 | 22/30 | |
EDS1000-4T0300G/0370P | 60/75 | 30/37 | |
EDS1000-4T0370G/0450P | 75/91 | 37/45 | |
EDS1000-4T0450G/0550P | 91/112 | 45/55 | |
EDS1000-4T0550G/0750P | 112/150 | 55/75 | |
3 phases 690v | EDS1000-7T0110G/0150P | 15/18 | 11/15 |
EDS1000-7T0150G/0185P | 18/22 | 15/18.5 | |
EDS1000-7T0185G/0220P | 22/28 | 18.5/22 | |
EDS1000-7T0220G/0300P | 28/35 | 22/30 | |
EDS1000-7T0300G/0370P | 35/45 | 30/37 | |
EDS1000-7T0370G/0450P | 45/52 | 37/45 | |
EDS1000-7T0450G/0550P | 52/63 | 45/55 | |
EDS1000-7T0550G/0750P | 63/86 | 55/75 | |
EDS1000-7T0750G/0900P | 86/98 | 75/90 | |
EDS1000-7T0900G/1100P | 98/121 | 90/110 | |
EDS1000-7T0110G/1320P | 121/150 | 110/132 | |
EDS1000-7T0132G/1600P | 150/175 | 132/160 | |
EDS1000-7T0160G/2000P | 175/215 | 160/200 | |
EDS1000-7T0200G/2200P | 215/235 | 200/220 |
Item | Item description | |||
Input | Rating volt., frequency | 1 phase 220V grade, 1 phase 220V ,50Hz/60Hz; 3 phase 220V grade, 3 phase 220V ,50Hz/60Hz; 3 phase 380V grade, 3 phase 380V ,50Hz/60Hz; 3 phase 690V grade, 3 phase 690V ,50Hz/60Hz. | ||
Allowed work volt. range | 1 phase 220V grade: 200V~260V; 3 phase 220 V grade: 200V~260V; 3 phase 380 V grade: 320V~460V; 3 phase 690 V grade: 586V~760V; | |||
Output | Voltage | 220V grade: 0~220V; 380V grade: 0~380V; 690V grade: 0~690V; | ||
Frequency | 0Hz-400Hz | |||
Over loading capacity | G type: 150% of rating current for1 minute, 200% of rating current for 0.5 second; P type: 120% of rating current for 1 minute; | |||
Control performance | Control mode | Speed sensorless slip vector control, open loop V/F control | ||
Speed regulation range | 1: 100 | |||
Start-up torque | 150% of rating torque at 1 Hz frequency | |||
Running speed stable state precision | ≤±0.5% of rating synchronous speed | |||
Frequency precision | Digital setting: max. frequency×±0.01%;analog setting: max.frequency×±0.5% | |||
Frequency resolution | Analog setting | 0.1% of max. frequency | ||
Digital setting | precision : < 100Hz 0.01Hz; ≥100Hz: 0.1Hz | |||
Exterior impulse | 0.5% of max. frequency | |||
Torque boost | Automatic torque boost, manual torque boost 0.1%~12.0% | |||
V/F curve (volt. frequency characteristic) | Set rating frequency randomly at range of 5~400Hz, can choose constant torque, degressive torque 1, degressive torque 2, degressive torque 3 and user-defined V/F in total 5 kinds of curve | |||
Accelerating decelerating curve | 2 modes: straight line accelerating decelerating and S curve accelerating decelerating; 7 kinds of accelerating decelerating time (unit minute/second can be optioned), max. time 6000 minutes. | |||
Brake | Power consumption brake | Interior or exterior brake resistance. 690 V grade haven't build-in brake unit . | ||
DC brake | Optional start-up and stop, action frequency 0~15Hz, action volt. 0~15%, action time 0~20.0 s | |||
Jog | Jog frequency range: 0.50Hz~50.00Hz; jog accelerating decelerating time 0.1~60.0s can be set | |||
Multisection speed running | Realized by interior PLC or control terminal | |||
Interior PID controller | Be convenient to make closed-loop system | |||
Automatic energy save running | Optimize V/F curve automatically based on the load to realize power save running | |||
Automatic volt. regulation (AVR) | Can keep constant output volt. When power source voltage varies. | |||
Automatic current limiting | Limit running current automatically to avoid frequent over-current which will cause trip | |||
Running function | Running order specified channel | Key pad specified, control terminal specified, serial port specified. | ||
Running frequency specified channel | Digital provision, analog provision, impulse provision, serial port provision, combined provision, can be switched at any time by kinds of method. | |||
Pulse output channel | Impulse square wave signal output of 0~20KHz, can realize output of physical parameter such as setting frequency, output frequency etc. | |||
Analog output channel | 2 channel of analog signal output, thereinto AO1 channel can be 4~20mA or 0~10V and AO2 channel is 0~10V; through them the inverter can realize output of physical parameter such as setting frequency, output frequency etc. | |||
keypad | LED display | Can display setting frequency, output frequency, output voltage, output current etc. | ||
Lock the button | Lock all or part of the buttons(analog potentiometer can't be locked) | |||
Protection function | Over-current protection, over-voltage protection, lack-voltage protection, over-heat protection, over-load protection, etc. | |||
Fitting parts | brake subassembly, remote-control keypad, connecting cable for remote-control keypad etc. | |||
Ambient | Use ambient | Indoor, not bare to sunlight, no dust, no corrosive gas, no flammable gas, no oil fog, no vapor, no water drop or salt etc. | ||
Altitude | Lower than 1000m, if higher than 1000m, need to reduce amount to use. | |||
Ambient temperature | -10ºC~+40ºC(under ambient temperature 40ºC ~50ºC, please reduce the volume or strengthen heat sink) | |||
Ambient humidity | Smaller than 95%RH, no condensation water | |||
vibration | Smaller than5.9m/s²(0.6g) | |||
Storage temperature | -40ºC~+70ºC | |||
Configuration | Defending grade | IP20 | ||
Cooling mode | By fan with automatic temperature control | |||
Mounting mode | Wall hanging |
Application
EDS1000 series variable frequency drives are mainly used in woodworking machinery, stone machinery, mining machinery, printing machinery, packaging machinery, food machinery, textiles, chemicals, transport, wire and cable, ceramics, building materials, tobacco and other industrial applications.
