Cutting Fluid Cooler (Coolant Chiller)
Request a Quote
-
Model: ICQ-0.6~ICQ-15
-
Cooling Capacity: 1.6-45.0kW
-
Temperature precision: ±0.5/±1.5°C
The cutting fluid (coolant) chiller is a dedicated support unit for CNC machine tools and machining centers. It continuously cools cutting fluid through forced refrigeration, helping maintain tool hardness, extend tool life, and ensure machining accuracy by preventing thermal deformation caused by high temperatures. Additionally, it inhibits bacterial growth, prolongs the service life of the cutting fluid, and is a key auxiliary device for improving the quality and efficiency of automated machining processes.
System Diagram
- Inlet
- Tank
- Pump
- Evaporator
- Flow switch
- Outlet
- Pressure gauge
- Compressor
- Cooling fan
- Condenser
- Dry filter
- Expansion valve
Specifications
| Model | | | | | | | ||
| Cooling capacity | kW | 1.6 | 2.7 | 3.5 | 5.2 | 9 | 12 | |
| 10³ kcal/h | 1.4 | 2.3 | 3 | 4.5 | 7.8 | 10.3 | ||
| Power supply | V/Ph/Hz | 220/1/50 | 380/3/50 | |||||
| Total power input | kW | 0.62 | 0.9 | 1.4 | 1.8 | 2.5 | 3.4 | |
| Rated current | A | 2.8 | 4.1 | 6.5 | 8.3 | 5.2 | 6.6 | |
| Compressor | Type | High efficiency rotor type | Flexible scroll type | |||||
| Power | kW | 0.5 | 0.8 | 1.2 | 1.6 | 2.3 | 3.2 | |
| Condenser type | High efficiency internal thread fin type | |||||||
| Evaporator type | Stainless steel coil type | |||||||
| Noise level | dB(A) | 56 | 58 | 62 | 63 | 63 | 67 | |
| Weight | kg | 40 | 70 | 80 | 90 | 110 | 140 | |
| Dimensions | Length | mm | 420 | 500 | 600 | 600 | 680 | 750 |
| Width | mm | 420 | 500 | 600 | 600 | 680 | 750 | |
| Height | mm | 815 | 950 | 1160 | 1160 | 1360 | 1480 | |
| Model | | | | | | | ||
| Cooling capacity | kW | 15 | 18 | 24 | 30 | 35 | 45 | |
| 10³ kcal/h | 12.9 | |||||||
| Power supply | V/Ph/Hz | 380/3/50 | ||||||
| Total power input | kW | 4.7 | 5.7 | 7.6 | 9.8 | 11.3 | 13.8 | |
| Rated current | A | 10 | 10.3 | 18 | 21.5 | 21.4 | 25 | |
| Compressor | Type | Flexible scroll type | ||||||
| Power | kW | 4.2 | 5.1 | 7.6 | 8.7 | 10.1 | 12.5 | |
| Condenser type | High efficiency internal thread fin type | |||||||
| Evaporator type | Stainless steel coil type | |||||||
| Noise level | dB(A) | 67 | 68 | 69 | 69 | 70 | 70 | |
| Weight | kg | 180 | 200 | 230 | 260 | 290 | 320 | |
| Dimensions | Length | mm | 750 | 750 | 1350 | 1510 | 1510 | 1785 |
| Width | mm | 750 | 750 | 680 | 750 | 750 | 915 | |
| Height | mm | 1480 | 1480 | 1360 | 1480 | 1480 | 1630 | |
Customized specifications are available upon request. Please
