Wheel Loader ZL60EV

ZL60EV is a heavy-duty 6-ton electric wheel loader designed for high-intensity operations in mining, quarrying, port handling, and large-scale infrastructure projects.

Powered by dual permanent magnet synchronous motors, including a 200 kW travel motor and a 140 kW hydraulic motor, the machine is also equipped with a high-capacity LFP battery system. It delivers a maximum breakout force of 175 kN and a traction force of 171 kN, matching the performance of conventional diesel loaders while achieving zero on-site emissions and significantly lower operating costs.

With 4–8 hours of operation per charge, intelligent electronic control, and integrated thermal management, this heavy-duty wheel loader ensures stable performance under demanding conditions. Engineered for global deployment, it combines a heavy-duty structural design with advanced electric-drive technology to provide a reliable and sustainable solution for modern material handling operations.

Video

Rated Load: 6000KG
Travel Motor: 200kW
Hydraulic Motor: 140kW
Rated Bucket Capacity: 4.5m³

Technical Specification
Rated load (kg)	6000
Operating mass (kg)	19200(1±5%)
Bucket capacity (m³)	3.5-4.5
Lifting time (s)	5.1
Unloading time (s)	1.3
Gradeability (°)	30
Max. traction force (kN)	171
Max. breakout force (kN)	175
Battery life (h)	4-8
Motor System
Torque (N.m)	Travel motor: 1200 / hydraulic motor: 350
Output (kW)	Travel motor: 200/ hydraulic motor: 140
Speed (rpm)	0-6000
Battery System
Battery type	LFP
Battery options	400kWh – Qiyuan Green Power
Battery options	Replaceable battery design

6-Ton Heavy-Duty Performance Provides strong lifting and climbing capability comparable to traditional diesel loaders, making it suitable for mining and continuous heavy-load operations.
- Rated load: 6000 kg
- Max breakout force: 175 kN
- Max traction force: 171 kN
- Gradeability: 30°
High-Capacity LFP Battery with 4-8 Hours Runtime High-capacity LFP battery system ensures safe operation, long service life, and stable performance in both high- and low-temperature environments.
- Battery type: Lithium Iron Phosphate (LFP)
- Battery configuration: Replaceable battery design
- Capacity: 400 kWh (optional)
- Battery life: 4–8 hours
- Management system: Intelligent Thermal Management System (ITMS)
Dual Motor Independent Drive System The independent drive system improves energy efficiency, optimizes power distribution, and enhances responsiveness across different operating conditions.
- Travel motor: 200 kW
- Hydraulic motor: 140 kW
- Torque system: Precise electronic torque control (ETC)
- Operating condition: Four selectable working modes
Reduced Operating Cost & Enhanced Reliability This heavy-duty wheel loader lowers the total cost of ownership (TCO) through simplified maintenance and improved operational safety.
- No fuel consumption
- Integrated PDU safety management
- No engine oil or exhaust system maintenance
- IP67 protection rating for high-voltage components
