Color Steel Tile Roll Forming Machine
Features
The product of this roll forming machine features novel appearance, level surface, uniform ripple, high usage and automatization, low cost and durability.
Application
The product of our color steel tile roll forming machine is widely used in civilian construction, such as plants, hangar, gymnasium, exhibition hall and theaters.
Technical Data
- Width of coil1000/1250mm
- Thickness of raw plate0.4-0.8mm
- Steps of rollers13-16 stations
- Material of rollersgood 45# steel, rigid chrome coated
- Material of roller shaftgood 45# steel
- Material of pressing mouldGCr15
- Material of cutting bladeCr12
- Depth of pitchcan be 15-20mm, one pressing mould for one depth
- Main motor power4kW
- Hydraulic motor power5.5kW
- Hydraulic pressure10-12MPa
- PLC controlPLC, touch screen, inverter and encoder are from Japan
