Wind Turbine
Request a Quote
Crafted from robust aluminum alloy, the body of the wind turbine houses a three-phase AC permanent magnet synchronous generator, providing reliable and efficient power.
Features
- Aesthetically pleasing
- Low starting wind speed
- Low running vibration
- Remarkable efficiency in converting wind energy
- Easy to install
Technical Parameters
Model | HY-600 | |
Rated power (W) | 600 | |
Rated voltage (VDC) | 24 | 48 |
Max. power (W) | 750 | |
Start-up wind speed (m/s) | 2.0 | |
Cut-in wind speed (m/s) | 2.5 | |
Rated wind speed (m/s) | 12 | |
Survival wind speed (m/s) | 50 | |
Rotor diameter (m) | 1.75 | |
Quality of blades | 5 | |
Noise (dB) | < 20 dB (based on 5m/s wind speed) | |
Generator type | Three phase permanent magnet direct drive | |
Tower connection | Flange connection or bolt-on clamp | |
Net weight (kg) | 25 | |
Ambient temperature (°C) | -40~60 | |
Strong wind protection | Electromagnetic brake, aerodynamic brake | |
Dimensions | 1250×520×250mm | |
Weight | HY-600H (3 blades) net weight: 21kg; gross weight: 24kg | |
HY-600L (5 blades) net weight: 25kg; gross weight: 28kg |
Model | HY-1000L | ||
Rated power (W) | 1000 | ||
Rated voltage (VDC) | 24 | 48 | 110 |
Max. power (W) | 1200 | ||
Start-up wind speed (m/s) | 2.5 | ||
Cut-in wind speed (m/s) | 3.0 | ||
Rated wind speed (m/s) | 12 | ||
Survival wind speed (m/s) | 50 | ||
Rotor diameter (m) | 1.95 | ||
Quality of blades | 5 | ||
Noise (dB) | < 20 dB (based on 5m/s wind speed) | ||
Generator type | Three phase permanent magnet direct drive | ||
Tower connection | Flange connection or bolt-on clamp | ||
Net weight (kg) | 30 | ||
Ambient temperature (°C) | -40-60 | ||
Strong wind protection | Electromagnetic brake, aerodynamic brake | ||
Dimensions | 1470×530×270mm | ||
Weight | HY-1000L(5 blades) net weight: 27.5 kg; gross weight: 37kg |
