Natural Gas Compressor

Request a Quote

View All: http://ksdrillrig.com/11-6-natural-gas-compressor/177063/index.html

The core technology of our natural gas compressor is from Dr. Tang with our R&D center in North America. The Y-4 natrual gas supercharger comes with highly energy-saving design. It is manufactured with advanced techniques and tested by world leading equipment. The efficient quality control system has ensured the consistent quality of our products. Besides our natural gas compressor is efficient, energy-saving, and produces limited noise. The product reliability has reached the highest level around the world.

The minimum gas inlet pressure could reach -40KPa, while the gas discharging pressure is 0.3-1.2 barg. The gas discharging capacity is 3-252m³/min. You can choose the proper type from the product list below.

Feature
1. This natural gas compressor is a piece of highly automatic gas compressing equipment. It doesn't need human monitoring.
2. Precise synchromesh gear is used for the driving system, giving rise to higher efficiency and better reliability.
3. A number of VI (visual identity) design are available.
4. As an energy-saving gas compressing machine on different working conditions. Comparing with roots blower, our natural gas compressor can save 35% energy at most.

Application
Gas station, coalbed gas extraction and conveying, shale gas pressurization, gas burning with air blowing, oxidation sweetening, and so on.

Parameter

Type	Rated rotation speed	Max. rotation speed	Rated capacity (m³/min)	Max. capacity (m³/min)	Discharge pressure of single stage (barg)	Shaft power (Rated- rotation speed, 1.2barg discharge pressure, kW)	Driving method
Type	Rated rotation speed	Max. rotation speed	Rated capacity (m³/min)	Max. capacity (m³/min)	Discharge pressure of single stage (barg)		Direct con- nection	Belt driving
B104	2950	9100	3	9	0.3-1.2	6	√	√
B124	2950	7600	5	13	0.3-1.2	11	√	√
B140	2950	7400	7	18	0.3-1.2	15	√	√
B158	2950	7200	10	26	0.3-1.2	21	√	√
B178	2950	6400	15	33	0.3-1.2	32	√	√
B196	2950	6300	20	43	0.3-1.2	40	√	√
B224	2950	5500	30	56	0.3-1.2	63	√	√
B247	2950	5000	40	69	0.3-1.2	83	√	√
B280	2950	4400	59	89	0.3-1.2	123	√	√
B311	2950	3900	81	109	0.3-1.2	168	√	√
B344	2950	3800	109	144	0.3-1.2	227	√	√
B382	2950	3700	152	193	0.3-1.2	316	√	√
B408	2950	3700	250	252	0.3-1.2	412	√	√
