Bundy Tube Straightener & Cutter
This Bundy tube straightener & cutter is for straightening coil Bundy tubes and capillary copper tubes, detecting length and burrless cutting automatically.
This machine adopts pull-apart cutting technology which is the most advanced cut-off method in the world, which eliminates or minimizes tube ID reduction that could occured and brings burr-less cutting result as well.
Main Features
- Servo feeding, stable and high re-positioning precision
- One time cutting two pieces, high efficient
- Adopting pull-apart technology, less tube end ID reduction ratio
- Orbited cutter with spray lubricant, burrless cutting
- PLC control, high automation—auto feed, auto cut, auto counting, auto alarm.
Technical Data
- Suitable tubeCoil copper tube TP1/2 (M/M2) / Bundy tube
- Suitable tube diameter rangeФ4.6~Ф10.6mm
- Suitable tube wall thickness0.5~1.0mm
- Cutting length range40mm ~ unlimited
- Pay-off device1
- Tube coil reel sizeOD: 400~600mm; Weight: max. 100kg
- Cutting pipes one time2
- Cutting speed8 cuts per minute (@L=1000mm)*
- One-time feeding strokeContinuous feeding, no length limit
- Cut-to-length tolerance≤0.3mm /1000mm
- Tube mouth ID reduction ratiof < 20% *
- Length difference among two pieces≤0.5mm
- Roundness of cut tubesNon-roundness ≤3%
- Surface condition after cutNo apparent scratch, drawing marks; no burrs
- Compressed air0.5-0.7MPa
- Total electric consumption1.0kW
- Main machine dimension2600 x 1200 x 1500mm
- Pay-off device dimension2000 x 1000 x 2000mm
* 1-When cutting length is less than 100mm, there will be no pre-stretching function.
* 2- Tube end ID reduction ratio means:
