φ12mm Optical Mounting Posts
Request a Quote
The 4 series ofφ12mm optical mounting posts: WN01SP、WN02SP、WN03SP、WN04SP. The posts are made of stainless steel, the available height is 25mm-300mm. The posts have wide application, can be used with other adjusting rack in our company.
Features- It is made of high quality stainless steel with high precision and good look.
- Multiple models to meet different needs.
- The mounting post can also be used with other adjusting rack in our company.
Model | WN01SP25 | WN01SP50 | WN01SP75 | WN01SP100 | WN01SP150 | WN01SP200 | WN01SP300 | |
Diameter | 12 mm | |||||||
Screw thread | One side is M6 male screw, another is M6 female screw. | |||||||
L | 25 | 50 | 75 | 100 | 150 | 200 | 300 | |
H | 8 | 15 | 25 | 30 | 50 | 60 | 100 | |
Weight | 0.025 kg | 0.05 kg | 0.075 kg | 0.1 kg | 0.015 kg | 0.2 kg | 0.3 kg | |
Model | WN02SP25 | WN02SP50 | WN02SP75 | WN02SP100 | WN02SP150 | WN02SP200 | WN02SP300 | ||||
Diameter | 12 mm | ||||||||||
Screw thread | Both sides are M6 female screw | ||||||||||
L | 25 | 50 | 75 | 100 | 150 | 200 | 300 | ||||
H | none | 25 | 30 | 30 | 50 | 60 | 100 | ||||
Weight | 0.025 kg | 0.05 kg | 0.075 kg | 0.1 kg | 0.015 kg | 0.2 kg | 0.3 kg | ||||
Model | WN03SP25 | WN03SP50 | WN03SP75 | WN03SP100 | WN03SP150 | WN03SP200 | WN03SP300 | |
Diameter | 12 mm | |||||||
Screw thread | one side is M4 female screw, another is M6 female screw. | |||||||
L | 25 | 50 | 75 | 100 | 150 | 200 | 300 | |
H | none | 25 | 30 | 30 | 50 | 60 | 100 | |
Weight | 0.025 kg | 0.05 kg | 0.075 kg | 0.1 kg | 0.015 kg | 0.2 kg | 0.3 kg | |
Model | WN04SP25 | WN04SP50 | WN04SP75 | WN04SP100 | WN04SP150 | WN04SP200 | WN04SP300 | |
Diameter | 12 mm | |||||||
Screw thread | Both sides are M4 female screw | |||||||
L | 25 | 50 | 75 | 100 | 150 | 200 | 300 | |
H | 无 | 25 | 25 | 30 | 50 | 60 | 100 | |
Weight | 0.025 kg | 0.05 kg | 0.075 kg | 0.1 kg | 0.015 kg | 0.2 kg | 0.3 kg | |
