Baler Machine (Energy-Saving)
Request a Quote
The energy-saving baler machine is designed for the compression and packaging of a variety of bulky waste such as paper, cardboard, cartons, books, magazines, plastic films and bottles, straws, and more to facilitate transportation and recycling.
With a low-energy motor, the energy-saving baler reduces the system’s energy consumption by about 20% while still meeting daily baling amount requirements, making it an ideal for a daily baling capacity of less than 100 tons.
The compression is repeated every 15~19 seconds. For different materials, there will be 7~15 bales packed per hour, with a weight ranging from 0.5 tons to 1.3 tons and the density of 500 kg/m3.
Features
- This is a fully automatic and unmanned baling machine that is suitable for material packing with a daily processing capacity of more than 20 tons.
- A photoelectric switch can be installed upon request to activate the baler when the hopper is filled with material.
- With a simple structure, the automatic baler machine is driven using a unique hydraulic system for faster baling.
- The open end facilitates the bale discharging performance and improves work efficiency.
- Jointly controlled by a Schneider or Mitsubishi PLC system and button or touch screen, the waste bale comes with feeding detection and automatic compression functions.
- The bale length can be freely set and the baling value can be accurately recorded.
- The cutting blades are forged using a high-quality carbon steel to prolong the service life and increase cutting efficiency.
- We provide a complete set of installation and operation instructions to help improve maintenance efficiency.
Custom options
- Size
- Motor configuration
Recommended models
| Model | FDY-850 | FDY-1250 |
| Bale size | Variable × 1100 (W) × 850 (H) mm | Variable × 1100 (W) ×1250 (H) mm |
| Bale weight | 700 kg | 1000 kg |
| Volume | 450 kg/m3 | 500 kg/m3 |
| Capacity | 3-4 t/h | 5 t/h |
| Hopper size | 1600 (L) × 1100 (W) mm | 1600 (L) × 1100 (W) mm |
| Pressure | 80-120 t | >=125 t |
| Power | 22-50 kw | 37-75 kw |
| Pump | 1-2 | 1-4 |
| Cycle | 20-30 s | 18-30 s |
| Binding | 3-5 | 3-7 |
