AL-PVC/AL-AL Blister Packaging Machine, DPP-250
Made on the basis of our company's manufacturing technology and experience for many years, the DPP-250 AL-PVC or AL-AL blister packaging machine has adjustable stroke, split structure, photoelectric register, capsule turning around and arranged according to color, and many other characteristics. This machine can conduct compound seal packaging for products in pharmaceutical, food, chemical and other industries.
Features- The AL-PVC/AL-AL blister packaging machine offers versatile speed control through frequency conversion, along with adjustable travel. It features touch-based heating, positive pressing for shaping, and capsule turning heads. It also has picture registration, an air washer for heat sealing, and upper and lower net lines, ensuring precision without cross-ward waste edges.
- The user-friendly human-machine interface includes a sensor test and a rejecting device for enhanced quality control.
- djustments for shaping, creasing, and punching positions are simple thanks to a hand-wheel designed for precise control.
- Moulds are secured with a fixed pin, ensuring an accurate and easier mould changes.
- It's not just for standard medicines; the blister packaging machine can also process a variety of materials and handle special-shaped items in one plate, making it highly versatile.
| Cutting Frequency (standard) | AL/AL: 15-25 times/min | |
| AL/Plastic: 20-35 times/min | ||
| Production Capacity | AL/AL: 75000 pc/h | |
| AL/Plastic: 140000 pc/h | ||
| Travel Range | 30-140 mm | |
| Max. Forming Area | 240×130 mm | |
| Max. Forming Depth | AL/AL: 18 mm | |
| AL/Plastic: 25 mm | ||
| Standard Sheet | 80×57×4 mm | |
| Total power | 5.5 kW | |
| Elec. Motor Power | 1.5 kW | |
| Air Supply | ≥0.2 m³/min | |
| Packaging Material (D×W) | PVC for medicine | 0.25×250 mm |
| Aluminum foil for hot seal | 0.02×250 mm | |
| Aluminum foil for forming in AL-AL packing | 0.16×250 mm | |
| Overall Dimensions (L×W×H) | 3100×670×1650 mm | |
| Weight | 1500 kg | |
Due to the advanced technology, this blister packaging machine passed the identification of scientific and technological achievements in Zhejiang Province and was ranked as national key new product. Meeting requirements of GMP, this machine has been sold to domestic and international pharmaceutical factories and large and medium-sized hospital, and has been exported to India, Pakistan, Malaysia, Burundi, Hong Kong, Taiwan and other countries and regions.
With small volume, light weight and compact structure, the AL-PVC or AL-AL blister packaging machine is easy to operate and convenient to maintain. Adopting frequency stepless speed regulation, the machine has a maximum blanking frequency of 35 times per minute and the stroke can be adjusted within 40-110mm. Our product uses plate-type mould and positive pressure forming. It will automatically stop and alarm when the tablet is broken or runs out. A universal feeder is optional and its filling ratio is over 99.5%. The feeder can be equipped with a suction inlet to eliminate the dust problem arising in the feeding process.
Jiangnan Enterprise is an AL-PVC/AL-AL blister packaging machine manufacturer and supplier in China. We offer a comprehensive range of products, including automatic medicine packaging production line, automatic capsule filling machine, tablet press machine, double cone medicine mixer, and more.
