Emulsifying Mix Tank

Emulsifying Mix Tank
Request a Quote

Emulsifying mix tanks are widely used for high speed mixing and emulsifying materials in the food, beverage, and cosmetics industry.

Form
Technical Parameters
Volume (L) Power (kW) Nominal Diameter (mm) Speed (r/min) Nominal Pressure of Tank Body (MPa) Nominal Pressure of Jacket (MPa)
100 1.1 500 1400/2900 0.1-0.25 0.25
200 1.5 600 1400/2900 0.1-0.25 0.25
500 2.2 800 1400/2900 0.1-0.25 0.25
1000 4.0 1000 1400/2900 0.1-0.25 0.25
1500 4.0 1200 1400/2900 0.1-0.25 0.25
2000 4.0 1200 1400/2900 0.1-0.25 0.25
2500 5.5 1400 1400/2900 0.1-0.25 0.25
3000 5.5 1400 1400/2900 0.1-0.25 0.25
4000 5.5 1500 1400/2900 0.1-0.25 0.25
5000 7.5 1500 1400/2900 0.1-0.25 0.25
