Manual Ball Valve, BV200

Manual Ball Valve, BV200
Request a Quote

Manually Operated Control Ball Valve in Plastic

BV200 manual ball valve features standard design, large flow rate and small torque. The optimized locking mechanism allows installation in two directions.


Specifications

    1. Size
      DN 15/20/25/32/40/50
    1. Pressure Level
      PN 10
    1. Body Material
      PVC-U, PVC-C, PP-H, PVDF
    1. Seal
      EPDM, FPM
    1. Connection
      true union (socket or spigot), flange
    1. Standard
      ISO 5211 standard

Features

Easy installation and maintenance

  • The optimized locking mechanism of ball valve allows installation in two directions.
  • Switch direction indication on the handwheel
  • ISO 5211 standard design with easy maintenance
  • Mounting base provided

Outstanding safety

  • Trapezoidal threaded union to prevent pop-off
  • Double seal valve base with low torque and without internal leakage
  • Broadest range of materials optional including high temperature and corrosion resistant materials

Excellent flexibility in configuration

  • Valve body: PVC-U, PVC-C, PP-H, PVDF
  • Seal: EPDM, FPM
  • Connection: true union (socket or spigot), flange
  • Connection standard: metric, US, JP

Application

  • Water treatment
  • PV
  • Integrated circuit
  • Electroplate
  • Glass panel
  • Electronic semiconductor
  • Power industry
  • Metallurgy
  • Petrochemical industry
  • Chemical engineering
  • Wind energy
  • Papermaking
  • Pharmacy
  • Food & beverage
  • Chlor-Alkali
