Rear Loader Garbage Truck
Description:
This rear loader garbage truck adopts Yellow Sea N3 base plate and hydraulic power. As one type of rear load garbage truck, this rear loader is able to automatically grasp the waste bins, dump, discharge the waste from transfer box. This rear loader is suitable for more than 90%waste bins on the market. The automatic spring shutter curtain is equipped above the transfer box to reduce the smelling out of waste.
The base plate is modified for higher power, lower noise, higher comfort, higher safety, lighter weight and smaller size. The rear loader is able to dispose and transfer garbage from larger area, and thus reducing the working strength of sanitation workers.
With easy operation and low maintenance, this rear loader is widely used for transferring the garbage in city and town.
| Model | BSQ5030ZLJDDG5 | Wheel Base (mm) | 3405 |
| Base Plate Model | DD1032B | Number of Axles | 2 |
| Motor Model | 4G69S4N (105KW) Base Plate National V Emission Standard | Highest Speed (km/h) | 150 |
| Dimension (mm) | 5708*1840*2310 | Number of Leaf Spring | -/5 |
| Total Weight (Kg) | 2735 | Number of Tires | 4 |
| Passengers (Person) | 2 3 | Tire Specification | 6.50RB16LT |
| Anti-Lock Braking System | Yes | Front Gauge | 1410 |
| Front Overhang/Rear Overhang (mm) | 895/1780 | Rear Gauge | 1425 |
| Recycling Time | 20s | Waste Dumping Time | 20s |
- The electricity of the truck provide the power for movable parts, no extra power is needed.
- The volume of trash container is 2m3, which is able to load 8-10 240L standard waste bins.
- Equipped with self-discharging tipping bucket and lifting device. The garbage is lifted to the top for dumping and discharged from the rear of the garbage truck. By this means, garbage collecting time can be saved, as well as garbage and waste water leakage can be reduced. This rear loader garbage truck is suitable for 120L, 240L standard waste bin by seamless connection.
- Be able to joint with trash compactor, leading to less garbage transfer time.
