Locking Ring binder Mechanism

Request a Quote

Website: http://clipsmanufacturer.com/2-2-locking-ring-binder-mechanism.html

3-Ring Locking Ring Binder Mechanism, 285mm Total Length

Item No.	Ring Distance	Total Height	Inner Height	Outer Width	Hole Distance	Total Length	Width of Mechanism
LOH285-3-38/26	108/108	43.5	31.5	44	243	285	26
LOF285-3-50/26	108/108	58.7	44.8	55.5	243	285	26
LOR285-3-65/36	108/108	76.6	60.5	73	243	285	36
LOR285-3-78/36	108/108	89.5	73.5	83	243	285	36
LOF285-3-78/45	108/108	89.5	72	84	243	285	45
LOSD285-3-38/26	108/108	46	34	52	243	285	26
LOSD285-3-52/26	108/108	60	49	55	243	285	26
LOSD285-3-63/36	108/108	75	60	71	243	285	38
LOSD285-3-76/36	108/108	86	70	76	243	285	36
LOSD285-3-78/45	108/108	89.6	72	87	243	285	45
LOSD285-3-102/45	108/108	115	98	88	243	285	45
LCSD285-3-127/45	108/108	142	125	100	243	285	45
LOS0285-3-127/55	108/108	145	125	118	243	285	55

Locking Ring Binder Mechanism, 300mm Total length

Item No.	Ring Distance	Total Height	Inner Height	Outer Width	Hole Distance	Total Length	Width of Mechanism
LOR300-30-18/22	9.5x29	23.5	12	22	123.5/123.5	300	22
LOR300-30-25/22	9.5x29	30	27.5	55.5	123.5/123.5	300	22
