  • JW-AX1 linear weigher with single head
  • JW-AX4 linear weigher with 4 heads
  • JW-AXS4 linear weigher with 4 heads
  • JW-AXM2 linear weigher with 2 heads
  • JW-AX2 linear weigher with 2 heads

Modular linear weighers are widely used for mixing, dosing, weighing and packing sliced, rolled and regular shaped products, as well as powder or small granule products such as sugar, seeds, rice, coffee powder, seasoning powder and more.

This series of modular linear weighers features manual feeding, though it can be equipped with an automatic bagging machine to create a complete packing production line.

Technical parameters for available model
Model JW-AX1 JW-AX2 JW-AXM2 JW-AX4 JW-AXS4
Product code X1-2-1 X2-2-1 XM2-2-1 X4-2-1 XS4-2-1
Single weighing range 20-1000g 50-3000g 1000-12000g 50-2000g 5-300g
Weighing accuracy class X(1) X(1) X(1) X(1) X(1)
Maximum weighing speed (Pack/Min) 10-15P/M 30P/M 25OP/M 55p/m 70p/m
Bucket volume 4.5L 4.5L 15L 3L 0.5L
Pre-installed parameter (set) 20 20 20 20 20
Maximum product type 1 2 2 4 4
Power 700W 1200W 1200W 1200W 1200W
Power supply 220V/50/60HZ/5A 220V/50/60HZ/6A 220V/50/60HZ/6A 220V/50/60HZ/6A 220V/50/60HZ/6A
Machine dimension(L × W × H) 860 × 570 × 920mm 920 × 800 × 890mm 1215 × 1160 × 1020mm 1080 × 1030 × 820mm 820 × 800 × 700mm
Advantages
  • All parts are made of food grade stainless steel for sanitary purposes.
  • The bucket doors are pneumatically controlled, feature automatic opening and closing.
  • Contact parts like pool bucket, discharge hopper, vibro plates, weighing buckets and so on are all easy to remove, making cleaning and maintenance easy.
  • Self-adjustment on the vibration frequency depends on the processing products.
  • You can modify the parameters during operation based on specific situations.
  • The modular linear weigher uses a stepless vibratory feeding system for more even spreading.
