Application
The plastic extrusion PET crystallizer dryer is designed by engineers for continuous crystallized amorphous phase materials. It is vital in the processing of raw PET materials or recycling materials that have not been crystallized. The crystallized materials can be mixed with PET new materials in a certain proportion and then undergo a dehumidification and drying process together. This minimizes production costs. We can customize PET crystallizer dryers in order to achieve crystallization drying effects according to the primary machine output of customers and according to their requirements.

Main components

Crystallizing tank

1. 80mm thick insulation layer observation door, convenient for real-time monitoring.
2. Wrapped with 80mm aluminum silicate cotton to lock in heat and save energy.
3. Anti-eccentric blanking device, uniform blanking, no material fault and single side blanking
4. Installed with ladder and fence, safe for workers to install and maintain.
5. The one touch pneumatic cyclone filter dust collector is simple and easy to maintain, reducing the incidence of burning and other accidents

Drying tank

① 80mm thick insulation layer observation door, convenient monitoring.
② Wrapped with 80mm thick aluminum silicate cotton preserves the heat within and saves energy.
③ Anti-eccentric feeding device, uniform blanking, no material fault and single side blanking

Dehumidifier
Dimensions (L*W*H)
Small 1000*1400*1910mm
Medium 1250*1900*2300mm
Large 1600*2050*2300mm

The body is designed compact to save space.

Different models of dehumidifiers can be selected according to different materials and different capacity.
Raw material Drying time h Drying temperature ℃ Water content before drying % Water content after drying % HD150 HD200 HD300 HD400 HD500 HD600 HD800 HD1000 HD1200 HD1600 HD2200 HD2600 HD3000
ABS extrusion 3-4 80-85 ﹤0.2 ﹤0.015 70 90 135 180 225 270 360 450 550 720 900 1000 1300
ABS injection 2-3 85 ﹤0.2 ﹤0.020 75 100 150 200 250 300 400 500 600 800 1000 1200 1500
ABS/PC 3 100 ﹤0.1 ﹤0.020 75 100 150 200 250 300 400 500 600 800 1000 1200 1500
CA 2-3 70 ﹤0.7 ﹤0.020 75 100 150 200 250 300 400 500 600 800 1000 1200 1500
  • Electroplax
    1. The dew point temperature can reach -60 C.
    2. SIEMENS electronic components are configured.
    3. 10 inch color PLC control panel, simple and easy to operate.

  • External filter core, convenient for cleaning.
  • External filter core, convenient for cleaning.
  • Condenser
    The condenser is easy to disassemble and to maintain.

  • Equipped with two molecular sieve tower, alternate operation, continuous low dew point dry wind.
  • The regenerated gas is cooled to the ambient temperature and discharged.

Feeder

The HF feeder series is equipped with a high efficiency vacuum pump with a delivery capacity of up to 1200 kg/h, the maximum conveying distance of 100 meters. It is configured with a cylinder filter which is tightly structured and combines the cyclone effect with dust separation, and is especially suitable for the delivery of dust laden materials

Features
1. Maintenance free motor, convenient filter core cleaning.
2. Noise level is lower than 78DB (A)
3. Vertical design scheme, small covering area.

The recycling of PET material is intended to minimize the wasting of resources. Hejin Plastic Machinery has carried out significant research and experiments on PET recovery and recycling, developed high efficiency crystallizers, and contributed its efforts to the recovery and crystallization of PET.

The Hejin crystallizer series is currently accounts for around 60% of the market of PET extrusion equipment in China. At the same time, the machines have been exported to the UAE, South America, Southeast Asia and Russia. Therefore, we can ensure that our crystallizer dryer series has a reasonable price and maintains good performance.
