Miniature Air Lubricator

Miniature Air Lubricator
Request a Quote
  • Rated inlet pressure up to 140 PSI (10bar)
  • Ambient and fluid temperature: 41 °F to 140 °F (5 °C to 60 °C)
  • Min. flow of oil drop: See below, flow at the pressure of 0.5 Mpa (5.1 kgf/cm2)
  • 5 Oil drops/minute at 20°C temperature
  • Port threads: NPT, PT, or BSPP
  • Bowl material: Polycarbonate (with steel protective cover on APLS30-25 to APLL50-1)
Item # Port Size Min. Flow of Oil Drop (L/min)
Flow Capacity (L/min)
APLM20-12 1/8 15 800
APLM20-25 1/4
APLS30-25 1/4 30 1700
APLS30-33 3/8 40
APLL40-33 3/8 5000
APLL40-50 1/2 50
APLL40-75 3/4 6300
APLL50-75 3/4 190 7000
APLL50-1 1
