Double Sided Brush Sanding Machine (Left and Right)

Double Sided Brush Sanding Machine (Left and Right)
Request a Quote

Mingda’s double sided brush sanding machine (left and right) is equipped with a durable sanding brush to simultaneously complete brush sanding processes on different irregular wooden workpieces, particularly long strip workpieces. It is primarily used to sand wooden materials before painting, and thus ensure a fine, smooth surface. PLC controlled, it is easy to operate and adjust, ensuring it is applicable to an array of different wood materials.

Main components of the brush sanding machine are sourced from international suppliers with a high quality and exceptional stability and safety, including a Zei Hua taper sanding motor, Taiwan Mei Na rubber roller, Schneider, France, electrical elements, and Rexroth, German, frequency converter.

Specification
Model MD-2P-S
Spindle horsepower 1.5KW×2
Feeding horsepower 180W×4
Feeding speed(inverter speed) 6-15m/min
Minimum sanding length 370mm
Maximum sanding width 100mm
Maximum sanding height 100mm
Vacuuming mouth size 4 inch×2
Mechanical dimensions(L×W×H) 1450×930×1150mm
Machine weight 350KG
